Get creative withYoloBox Ultra. Elevate your broadcasts, engage your audience, and make an impact.

Whats NEW at a glance

• 4 HDMI Inputs –Connect More, Experience MoreAmplify Connectivity, Minimize Limitations
• ISO Recording-Preserve EveryPrecious Moment
• CellularBonding-Deliver rock-solidreliable videos
• 4KStreaming-Every Detail Comes Alive
• NDI/HX3& SRT-New ways to expandand evolve
• Stronger CPU-Innovation taken to newdepths & possibilities.
• BiggerBattery-75.48Wh,stream up to 6 hours.
• Bigger &Brighter-See Beyond,Shine Through

YoloBox & Instream In One,Angle it your way.

The combination of the YoloBox Pro and Instream becomes the YoloBox Ultra. Apart from the standard horizontal platforms, stream vertically to Instagram, TikTok without the necessity to purchase an Instream.

Mission-Critical Cellular Bonding.3 SIM Data, 5 Connections.

Experience unparalleled global internet connectivity wherever you go with YoloLivs Cellular Bonding. It can bond* up to 5 network connections across 4G LTE (1x), Wi-Fi (1x), Ethernet (1x), and USB Modems (2x) ensuring your stream never misses a beat event over the most challenging network conditions.

• Wi-Fi
• Cellular
• Ethernet
• USB Modem

Unleash the Power of Live Streamingwith Qualcomm CPU 865

Experience seamless and top-notch streaming performance with the new Qualcomm CPU 865.No matter how demanding your streaming needs are, this powerful processor has got you covered.Get ready for crystal-clear streams, minimal delays, and stunning visual quality that will leave you impressed.

• 2.5XCPU Performance
• 4XGPU Performance
• 2.3XRAM
• 4XROM

A Pro Tool, Made For Everyone

From simple tasks to most demanding professional client projects.

Specifications

• Ports
  • HDMI IN 1: Video input
  • HDMI IN 2: Video input
  • HDMI IN 3: Video input
  • HDMI IN 4: Video input
  • HDMI OUT: Video out to monitor or computer for Zoom/Skype meetings
  • ETHERNET PORT: Connect to Internet by Ethernet cable
  • USB Type-A 3.0: Video input( Support: webcam; portable storage device ; wireless usb dongle.)
  • USB Type-A 3.0: Video input( Support: webcam; portable storage device ; wireless usb dongle.)
  • USB Type-C: Only for charging
  • LINE IN(3.5mm): Stereo, connect to electric guitar or synthesizer
  • MIC IN(3.5mm): Mono, connect to microphone for recording
  • AUDIO OUT(3.5mm): Connect with monitor headphones
    • EPA Tier 3
    • EPA Tier 4
    • EPA Regulations
    • China National Standards
  • USB Type-C: A fully functional interface supports input
  • 1/4” Screw Hole: Mount Ultra with camera
  • Nano-SIM Card Holder: Insert SIM card to connect to Internet
  • SD Card Holder: Used for recording and loading graphics
  • Power Button: Turn on and turn off
• Input Power-DC5V/9V/, 12V/15V
• Power Consumption-45W
• Power Supply-USB Type-C
• USB Rated Output-USB-A:5V/1A
• Battery Capacity-6800mAh
• Monitor Screen Size
  • 8inch LCD Resolution: 1200*1920; Brightness: 650nits;
  • Contrast ratio(1500:1), Viewing Angle (full viewing Angle), NTSC 80%
• Local Video Inputs-HDMI,USB-A
• Video Over Ethernet-RTMP/RTMPS/SRT
• Video Input Connectors-HDMI,USB-A,RJ-45,USB Type-C
• Video Input Aspect Ratios-16:9; 4:3; 1:1
• Video Input Deinterlacing-No
• Live Broadcast Video input Resolution-480p/720p/1080p(up to 60fps)/4k 30fps
• Video Encoded Format-H.264 H.265
• Video processing Bitrate control-CQ, VBR, CBR
• Hardware-Accelerated Video Encoding-Optional
• Video Output Signal Types-FLV-RTMP,HDMI,UVC
• Video Output Connectors-HDMI OUT, USB-C
• Video Output Streaming protocols-RTMP, RTMPS, MJPEG, SRT
• Live Broadcast Video Output Resolution-480p/720p/1080p(up to 60fps)/4k 30fps
• Analog Audio Input Connectors-Line In, Mic In, 3.5mm
• Digital Audio Inputs-USB, HDMI, RTMP(From internet), Local video(From SD card)
• Digital Audio Input Connectors-USB-A, HDMI, USB-C
• Audio Input Mute-Yes
• Audio Input Format-32KHZ/44.1KHZ/48KHZ :16bit
• Audio Encoded Format-(AAC)44.1K/48KHZ 2Ch 16bit
• Analog Audio Output-3.5mm headphone jack
• Digital Audio Outputs-HDMI audio (Embedded), USB Audio (Embedded)
• Record Formats-MP4
• Wi-Fi –2.4G/ 5GSupport WiFi6)
• Dimensions (HxWxD) –1.07 x 5.51 x 8.62 inch (27.1 x 140 x 219 mm)
• Weight –2.16 lbs (981g)
