TheYellowtec Litt Base Controlleris the base unit of the Litt LED Signaling System. It supports up to five Litt Color Segments attached on top of it or a single Sound Segment. (A Sound Segment can also be used in a mix of multiple Color Segments, as long as it’s attached as the top-most one.) The Base Controller comes with a Windows control software for programming the Color and Sound Segments and has a mini-USB port for interfacing with your computer. It features a color-coded, 8-pin terminal block neatly positioned on the interior for the Litt Multicore System Cable that connects to the different segments. The segments and cable are sold separately. The Base Controller operates at 9-24V.

The Base Controller can be attached to any common-size desktop mounting platform using an included Mounting Kit. To mount it at an increased height, you can incorporate an optional Litt Riser. To mount it on a mic stand, you can screw in an optional Litt 3/8″ Base Controller Mounting Set into the threaded hole on the bottom. You can also plug the Base Controller directly into the top of an optional Yellowtec m!ka MMS System Pole, which is the mounting pole for m!ka MMS Monitor Arms.

The Litt LED Signaling System is suitable for any signaling application that can make use of visual signals, including studio and industrial applications. The Litt system has a clean and robust aluminum design.

Features

• Base Unit for Litt LED Signaling System
• Drive up to 5 Litt Color Segments
• Attach Single Litt Sound Segment
• Windows-Compatible Programming Software
• USB Computer Interface
• Desktop-Mount Kit Included
• Mic Stand Mount Adapter Supported
• Attach Directly into m!ka System Pole
• Clean and Robust Aluminum Design
• Reverse-Polarity Protection
