Choose the PUC2 Mic LEA USB Audio Interface to get perfect audio levels with your favored XLR-microphone. Thanks to its onboard LEA Level Energy Arbitration, PUC2 Mic LEA delivers perfectly leveled recordings. You dont need any time-consuming post-processing. LEA provides you with real-time audio processing and captures perfect levels without any clipping. PUC2 Mic LEA overcomes the problems of noisy recording environments and prevents any over- and under-loading.

PUC2 Mic LEA integrates the real-time LEA DSP Engine from Yellowtec’s iXm Recording Mic into a class-leading USB audio interface. Featuring one of the highest-quality mic preamps available, PUC2 Mic LEA ensures pristine audio quality with zero latency for your microphone signal. Use it to stream two channels of mic recordings via USB or use it as a standalone A/D converter with its preamp and LEA Level Energy Arbitration.’

Specifications

• Power: via Dual USB: < 1000 mA
• Clocking: jitter: < 15mUI Peak; frequency accuracy: +/- 10ppm
• Input selection: automatic with AES detection
• Digital input: format: AES3 + SPF/DIF; connectors: XLR; SUB-D module connections: SUB-D 25 pin; sampling rate: 44,1kHz, 48kHz, 88,2kHz, 96kHz, 176,4kHz, 192 kHz; bit depth: 24Bit
• Digital output: format: AES3; connectors: XLR; SUB-D module connections: SUB-D 25 pin; sampling rate: 44,1kHz, 48kHz, 88,2kHz, 96kHz, 176,4kHz, 192 kHz; bit depth: 24Bit
• Analog input: input level 1 (switchable): +18 dBu; impedance: mic typ 1,2kOhm, live typ 10kOhm
• Analog output (not balanced): adjustable volume; impedance: < 16Ohm, headphones with up to 600 Ohm can be used
• USB Connector: USB 2.0 Type B
• Phantom power: switchable; voltage: 48V; electricity: 5mA
• Headphone output: 6,3mm jack: adjustable volume; impedance: < 16Ohm, headphones with up to 600Ohm can be used
• Microphone input (electronically balanced): GAIN: 0,05%; Input referred noise: -127dBu @150Ohm; impedance: 1,2kOhm
• AD/DA Converter: dynamic: 108dB; THD+N ADC: -107dB THD+N; THD+N DAC: -103dB THD+N; sampling rate DAC: 44,1kHz, 48kHz, 88,2kHz, 96kHz, 176,4kHz, 192 kHz; bit depth: 24Bit
• Length: 185mm
• Width: 127mm
• Height: 41,5mm
• Weight: 600g
