ThePUC2fromYellowtecis a USB 2.0 audio interface with a pair of XLR inputs and outputs for balanced line-level signals, AES3 input and output over XLRs, and a 1/8″ (3.5mm) headphone output. The line-level XLR connectors can be set tovarious standard operating levels up to 18 dBu: +4 dBu, +6 dBu, or user-definable. The device is bus-powered and does not require any drivers in order to function. However, for added functionality and ease-of-use, an ASIO driver is available for free download.
Specifications
| Sampling Rates | ADC/DAC: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz |
| Bit Depth | 24-bit |
| Input Connectors | 2 x XLR inputs (balanced line level) 1 x XLR digital input (AES3, S/PDIF) |
| Output Connectors | 2 x XLR outputs (balanced line level) 1 x 1/8″ (3.5 mm) headphone output 1 x XLR digital output (AES3) |
| Total Harmonic Distortion (THD) + N | ADC: -107 dB DAC: -103 dB |
| Dynamic Range | 108 dB |
| Input Level Adjustment | Input Level 1 (Switchable): +6 dBu; +15 dBu maximumat full scale Input Level 2 (Switchable): +4 dBu; +18 dBu maximum atfull scale Input Level 3 (Switchable): +5 dBu at full scale |
| Input Impedance | 18 kOhms (typical) |
| Output Level Adjustment | Input Level 1 (Switchable): +6 dBu; +15 dBu maximumat full scale Input Level 2 (Switchable): +4 dBu; +18 dBu maximum atfull scale Input Level 3 (Switchable): +5 dBu at full scale |
| Output Impedance | 40 Ohms (typical) |
| Headphone Output Impedance | < 16 Ohms |
| Input Selection | Automatic with AES detection |
| USB Port | USB 2.0 Type-B |
| Clocking System | Jitter: < 15 mUI peak Frequency Accuracy: +/- 10 ppm |
| Power | Bus-powered (< 1000 mA) May require power from two USB ports |
| Dimensions | 7.3 x 5.0 x 1.6″ (185 x 127 x 41.5 mm) |
| Weight | 21.2 oz (600 g) |
Packaging Info
| Package Weight | 1.7 lb |
| Box Dimensions (LxWxH) | 7.7 x 5.3 x 2.5″ |
