hush+ is a convenient controller for your OnAir signaling. In addition to red light control, the hush+ model also allows you to control your microphone signal. Using hush+, you will find several settings in the hush App. hush+ allows for easy control over both, your OnAir LED signals and your mic signal. Its integrated preamp delivers highest available standards with gain from 12dB to 75dB at incredible -129dB input referred noise. On top, you benefit from its mute function and can control highpass filter and phantom power via hush App.

hush+’s plug’n’play concept allows fast handling. Made for m!ka, hush+ perfectly fits the XLR-5 connector at the bottom end of your m!ka Mic Arm OnAir’s cable. Simply plug’n’play! You’re instantly in control of your OnAir signaling. Manage your mic signal and make most of the m!ka Mic Arm’s dual-color LED indicator with hush+. If you are looking for OnAir control without preamp and mute function, please check out the hush OnAir Controller that loops through your mic signal unprocessed.

Thanks to five different modes, hush+ fits nearly any setup. Directly on the device or within the corresponding hush App you can select your preferred mode to control your hush device. Choose between the hush Remote, GPIs, USB-HID or MIDI (USB / Ext.). No matter your needs, hush+ supports you in the driver’s seat!

Features

• Premium device to control your OnAir signaling
• Allows for control over LED and mic signal incl. mute
• Designed to fit Yellowtec’s m!ka Mic Arms with OnAir indicator
• Plug’n’play concept for mic arm’s XLR-5 allows for fast handling
• Optionally also control a color segment of the litt Signaling Device
• Delivers highest available audio standards
• Integrated high-class preamp
• 12dB…75dB at -129dB input referred noise
• Adjust the gain of your mic signal in the hush App
• Switch on / off a highpass filter to remove unwanted rumble
• Activate or deactivate phantom power according to your mic’s needs
• Thanks to a great variety of modes, hush+ fits any setup
• Control hush+ via hush Remote, GPIs, USB-HID or MIDI (USB / Ext.)
• Sturdy aluminum unibody serves as a conductor + heat sink
• Dimensions: 18.5 x 12.7 x 4.5cm | Weight: 0.5kg
• An optional hush Remote is available

Specifications

Mic In

• Input Impedance: 1.2 kOhm
• Max. Input Level:+6 dBu
• Gain:12dB…75dB
• Input Referred Noise:-129dB
• Subsonic Filter:HP 80Hz 12dB/oct.

Phantom Power

• Voltage:48V +/- 5%
• Current:7mA / 10mA peak

Line Out

• Output Impedance: 40 Ohm
• Max. Output Level:+18 dBu
• THD+N:0,001%
• Frequency Range:20Hz – 20kHz

USB

• Connector: USB-C
• Compatibility: USB 1.1 – USB 2 (with PSU), USB 3 (fully USB-powered)
• Data Rate: 12 MB/sec

Power via USB

• Voltage: 4.5V ..5.5V
• Current: typically 500mA / 900mA max

Red Light Power @5-Pin XLR

• Output Voltage: 12V
• Output Current: 40mA

litt Control

• Output Voltage: 12V
• Output Current: 60mA

USB-HID

• Connector: USB-C

MIDI-In

• Current Loop: 10mA@5V
• Data Rate: 31.25 kBaud

GPI

• Type: Switch to GND

GPO

• Type: Open Collector
• Max. Voltage: +30V
• Max. Current: 1.5A
