WaveCAST C is a real-time audio over Wi-Fi platform designed for pro-audio applications where high-quality sound is required. Its integration with third-party room systems allows AVprofessionals to control and monitor the WaveCAST C using Telnet commands via Ethernet.
Audio is streamed to an app on personal devices or a Wi-Fi receiver, which can be used for assistive listening and other purposes.
Specifications
| Dimensions | 8.45 W x 8.25 D x 1.72H (21.5 cm x 21 cm x 4.4 cm) | |||
| Weight | Transmitter: 3.2 lbs (1.45 kg) | |||
| Color | Black | |||
| Rack Mount | Standard 19 Rack, one EIA rack space high, 1/2 space wide 12 units can be mounted in a single rack space with optional RPK 005 (single) or RPK 006 (double) Rack Mount Kits |
|||
| Power Supply | Desktop Style Transformer (TFP 062); Input: 100-240 VAC, 50/60 Hz. IEC Line Cord; Output: 24 VDC, 750 mA, 18W. 2.5mm ID center positive barrel connector | |||
| Power ON Indicator | Push On/Push Off latching power button with backlight. Green backlight indicates power ON, backlight off indicates power OFF. | |||
| Temperature Range | Operating: +32 F to +122 F (0 C to 50 C); Storage: -4 F to +158 F (-20 C to 70 C) | |||
| User Interface | 1. 3.12 High Resolution OLED display with selections via buttons. 2. Hosted Web page. 3. Telnet commands over ethernet (see our WaveCAST and FM+ Programmers Guide for available commands and protocol). | |||
| Dante | (1x) RJ-45 jack. Only available on WF T5CD | |||
| Ethernet | RJ-45 on back of unit supports CAT 5e cable lengths up to 328 feet (100 meters); 10/100 Base-T IEEE 802.3 compliant, unique MAC address. RJ-45 jack used for web page and streaming audio out. An external Router/DHCP Server is required to stream audio to receiving devices. | |||
| Audio Section | ||||
| Audio Inputs | (1x) Combination 3-pin XLR, 1/4 (TRS) jack for balanced or unbalanced line level, or balanced or unbalanced microphone with selectable phantom power. Optional RJ-45 Dante Input (D models only). | |||
| Audio Processor Functions | DSP based; Compression: 1:1, 1.5:1 or 2:1; High-pass and Low-pass Filter Frequency control, Music, Voice, and Hearing Assistance Audio Presets | |||
| Frequency Response | 31-16000 Hz, 3 dB (re: 1 kHz) (Music Audio Preset) | |||
| Signal-to-Noise Ratio | 64 dB (typical) Transmitted RF @ 1kHz | |||
| Total Harmonic Distortion | Less than 0.25% @ 1 kHz (RF output) | |||
| Common Mode Rejection | Greater than 57 dB @ 1 kHz, Mic or Line mode | |||
| Audio Input Gain Adjust | Adjustable from +24dB to -60 dB, in 1dB steps from front screen or web page | |||
| Phantom Power | 14.4 VDC applied through 2.2 kOhms resistors to analog combo jack: Pin 2 and Pin 3 on XLR jack, or tip and ring on 1/4 TRS jack | |||
| Audio Level Display | Front screen bar graph display, each segment representing 3dB. It ranges from -18 (1 segment lit) to +12dB (10 segments lit). Over-range warning is indicated by OLVD and flashing empty bar. | |||
| Headphone Output | 1/4 TRS stereo jack, mono signal, 7.8 mW total power with 33 . | |||
| Dante Output | (1x) RJ-45 jack, only available on WF T5CD | |||
| Input Level (Bal or Unbal) (at Audio Input Gain = 0dB) |
|
|||
| Microphone |
|
|||
| Line |
|
|||
| Approvals | FCC, RoHS3, WEEE, Industry Canada, CE, UK CA, RCM | |||
| Warranty | 2-year parts and labor |
