The DL210 NET 2.0 hearing loop amplifier maximizes modern amplifier technology. Its network-control capability provides seamless, remote system set-up, operation, and monitoring of the induction loop system via a laptop or tablet. DSP audio processing offers flexible, powerful software control of mixing, equalization, compression, and more. Powerful Class D pulse-width amplifier maximizes the efficiency of the unit.
This assistive listening systems design offers a dual 12 A rms loop output for dual loop or phased array configuration. A 70-100 V input connects to a distributed speaker/paging system, ensuring announcements are heard by hearing aid users.
Meet IEC 60118-4 standards on system performance when integrated into a correctly designed and installed system. The DL210 NET 2.0 is also tested to IEC Specifications 62489-1 Benchmark Standards.
Specifications
| GENERAL | |
| Dimensions | 2 RU Rackmount, 19 W x 3.5 H x 12 D. Chassis is 17 W. |
| Weight | 14.3 lbs (6.5 kg) |
| Color | Case: Black, white and blue legends on front, white legends on back. LCD: Backlit Blue. |
| Fan cooling | Variable Speed, Temperature Controlled |
| Power supply | Internal, Universal 100-240 VAC, 50/60 Hz, 250 Watt. Fuse: 5 x 20 mm, 5 A, 250 V.
AC power plug is IEC 320-C14. |
| Heat output @ 120 VAC | Sleep state: 100 BTU/hr; Idle state: 146 BTU/hr; Driving two loops @ 12 A each: 1,040 BTU/hr |
| Ethernet | (1x) RJ-45; 10-100 MBps. |
| USB | (1x) standard-B. USB 1.1, 2.0 or 3.0 supported. |
| RS-232/Loop fault relay | (1x) DB-9 jack. RS-232: Pin 2=Tx, Pin 3=Rx, Pin 5=gnd. Loop fault relay: Pin 1=NC, Pin 4=Common, Pin 6=NO. Relay contact rating: 2.0 A @ 30 VDC. |
| Environment | 0-35 C ( 32-95 F), 0-90% relative humdity. |
| Coverage area* | 31,400 sq. ft. (2,917 sq. m.) (Perimeter Loop, 1:1 aspect ratio, both outputs driven)
51,660 sq. ft. (4,800 sq. m.) (Perimeter Loop, 3:1 aspect ratio, both outputs driven) |
| INPUTS | |
| Dante input | No. Dante input available on DL210 NETD2.0 model only. |
| Mic/Line inputs | (2x) 3-position terminal block, input impedance=1.5 k Mic, 10 k Line. Configurable/Accepts: Mic, Line -10 dBV, Line +4 dBu, or Line +8 dBu, balanced or unbalanced. Phantom supply (48V). |
| 70-100 V input | (1x) 2-position terminal block; high/speaker-level input (accepts 25 V, 70 V or 100 V) from distributed audio/paging systems. |
| OUTPUTS | |
| Line outputs | (1x) 3-position terminal block; loop-through of Mic/Line Input 1 [&] Line Input 2, +4 dBu, Balanced or Unbalanced. The line outputs mirror the audio of the loop output. |
| Loop output(s) | (1x) 2-position terminal block per output |
| Audio output delay | Adjustable from 0 to 165 msec |
| Headphone output | (1x) 1/4 stereo headphone jack, on front of unit. Monitored input or output selectable in menu. |
| Loop fault relay | Integrated into RS-232 DB-9 jack. Pin 1=NC, Pin 4=Common and Pin 6=NO. Contact rating: 2.0 A @ 30 VDC. |
| Loop output drive voltage | 33.3 Vrms (47.1 Vpk) continuous |
| Rated loop output current* | 12 Arms(17 Apk) per output |
| Loop resistance range | 0.5 to 3.0 (DC) |
| Speaker output | Integrated into Loop Output A terminal block (switchable in menu). 225 Watts x 1 channel @ 4, 125 Watts x 1 channel @ 8, (Class D). Frequency response = 20 Hz-20 kHz, THD=0.07%. |
| AUDIO | |
| Rated load* | 0.5 DC with 135 H inductance |
| Loop frequency response | 45 Hz to 9.0 kHz 2 dB (1 kHz ref.) |
| Rated loop THD* | [lt]1 % at rated output current (1 kHz sine wave). |
| OTHER | |
| Front controls | Front LCD display menu access/adjustment via control button/dial. |
| Adjustable settings | Input mixing, parametric equalization, compression, metal loss compensation, high and low-pass filters, AGC and audio delay, output levels. See User Manual for adjustment range(s). |
| Internal calibration tools | Test tone generator with pink noise, loop current adjustment/matching. See User Manual for details. |
| Other features | Save/load configuration, loop test, priority input selection with adjustable threshold, loop fault relay, open/short and thermal protection. See User Manual for details. |
| Network control [&] firmware | Function control and calibration by DigiLoop PC App via ethernet (RJ-45). PC App requires Windows 7 or higher.
Firmware updates through USB only. |
| Warranty | 2 years |
| Approvals | CE, UL, ULC, FCC, Industry Canada, RoHS, WEEE, CB scheme, RCM |
| Standards compliance | This product is designed to meet the IEC-60118-4 standard when correctly designed, installed and commissioned.
Test Specifications provided to the IEC 62489-1 standard. |
