The Wharfedale Pro GPL-115B subwoofer is a 700 watt sub with 1400 W Programme, 4.0 LF Voice coil, EASE gll files available for download and easy fixings and brackets.Features:Compact birch plywood constructionBeyma Coaxial design driversMultiple mounting o
The Wharfedale Pro GPL-115B subwoofer is a 700 watt sub with 1400 W Programme, 4.0 LF Voice coil, EASE gll files available for download and easy fixings and brackets.
Features:
Specifications
| System Type | 15 Subwoofer |
| Configuration | Single Bass-Reflex Subwoofer |
| Frequency Response (+/-3 dB) (DP-N preset) |
/ |
| Frequency Range (- 10 dB) (DP-N preset) |
32 Hz 125Hz |
| Sensitivity 2.83 V/1 m | / |
| Sensitivity 2.83 V/1 m half space | 104 dB (half space) |
| Calculated Maximum SPL @1 m | 139 dB (half space) |
| System Peak SPL* | 145 dB (half space) |
| *level at 1 m using pink noise with crest factor 4, with dedicatedpreset. | |
| System Rated Impedance | 8 |
| Low Frequency Transducer | |
| Size | 404 mm / 15 |
| Voice coil size | 102 mm / 4 |
| LF Frame Material | Aluminium |
| Driver brand | Wharfedale Pro |
| POWER | |
| System Continuous Power (W) | 700 |
| System Programme Power (W) | 1400 |
| System Peak Power (W) | 2800 |
| Recommended HPF = BW 18 dB/oct. | 27 Hz |
| Input Connector | |
| Rigging & Hardware: | 12 x M10 threaded rigging points. |
| Included Accessories | |
| Handle | 4 on Sides |
| Enclosure | |
| Cabinet Type | Rectangle |
| Enclosure Material and finish | 18 mm plywood / Rhino Rock |
| Colour Options | Black paint, White on request |
| Grille Material & Finish | Powder coated steel |
| Dimensions Unpacked (mm / inches): | |
| Height | 530 mm / 20.9 |
| Width Front | 470 mm / 18.5 |
| Width Rear | 470 mm / 18.5 |
| Depth | 630 mm / 24.8 |
| Dimensions Packed (mm / inches): | |
| Height | 600 mm / 23.6 |
| Width Front | 530 mm / 20.9 |
| Width Rear | 530 mm / 20.9 |
| Depth | 690 mm / 27.2 |
| Weight | |
| Net Weight | 32.5 kg / 71.5 lbs |
| Gross Weight | 36.0 kg / 79.2 lbs |
