TheDSPro StageGrid 4000is an I/O interface designed for eMotion LV1 live mixing systems. It features 32 analog mic/line inputs and16 analog outputs, plus four channels of AES/EBU digital I/O. All channels are digitally controlled. Its two headphone outs have independent volume controls. All components are carefully selected and tested to ensure continuous system stability and maximum dependability, and there is a redundant power supply. Built in a robust 4U rack-mountable chassis, DSPro StageGrid 4000 provides a seamless solution for live sound applications, coupled with the modularity and power of SoundGrid technology.

SoundGrid is the Waves high-speed networking protocol for moving audio, clock, and other information between a host system and I/O devicesand between I/O devices themselves. A SoundGrid host manages the network and assigns servers and I/O devices to mix, process, and record, depending on the host. All SoundGrid devices connect to the host with standard Ethernet cable.

SoundGrid is scalable. Connect one I/O device to a DAW and you have a high-quality sound card. Add more I/Os and your system becomes more flexible and powerful. Depending on the host application, a SoundGrid host can assign up to sixteen I/O devices. Complete SoundGrid systems can be networked together to share devices.

Add a server to a SoundGrid system to offload plugin processing from the host CPU to a SoundGrid DSP server. This dramatically increases processing power and enables greater plugin counts, as well as providing very low system latency.

Features

• Supports sample Rates from 44.1 kHz to 96 kHz
• SoundGrid stagebox is perfect for the eMotion LV1 mixer
• 2 stereo headphone outs with individual volume controls
• 32 analog mic/line inputs with XLR connectors
• Word Clock input and output, with BNC connectors
• 16 analog line outputs with XLR connectors
• Ethernet connection for SoundGrid connectivity
• 4 stereo AES/EBU digital inputs and outputs, with XLR connectors
• Redundant AC power supply for live performance security
• Robust 4U rack-mountable chassis and premium components

Specifications

General

• 32 Analog mic/line Inputs
• 16 Analog line outputs
• 4 Stereo AES / EBU Digital inputs
• 4 Stereo AES / EBU Digital outputs
• Configurable Sample Rate of 44.1, 48, 88.2 and 96kHz
• Two headphone outputs
• Wordclock INOUT
• A SoundGrid Ethernet port
• Redundant Power supply

Analog Inputs

• Impedance: 2.86 kOhms
• Gain range: -4 dB to 60 dB
• Max input level: 28 dBu (-4 dB gain)
• Dynamic range: 115 dB (-60 dBFS, 20 dB gain, 1 kHz, A-weighted)
• THD: 0,002 % (-1 dBFS, 20 dB gain, 1 kHz, A-weighted)
• Equivalent input noise: -128 dBu (60 dB gain, A-weighted, 150 ohms)
• Frequency response: +/- 0.1 dB (20 Hz to 40 kHz at 96 kHz sampling rate)
• Phase Shift: <10 at 20 Khz

Analog Outputs

• Output impedance: 50 ohms
• Max output Level (0dBFS): 24 dBu
• Dynamic range: 115 dB (-60 dBFS, 1 kHz, A-weighted)
• THD: 0,002 % (-1 dBFS, 20 dB gain, 1 kHz, A-weighted)
• Frequency response: +/- 0.1 dB (20 to 40 kHz at 96 kHz) Phase shift: <5 at 20 Khz

AES/EBU IN/OUT

• Standard: AES3 (2009)
• Sample rates: 44.1, 48, 88.2 and 96 kHz
• Impedance: 110 ohms

Headphones

• Output Power: 150 mW per channel on 16 ohms
• Dynamic range: 100 dB

SoundGrid

• Interface: Gigabit Ethernet
• Connector: Neutrik EtherCON

Word Clock

• Connector: BNC
• Impedance: 75 Ohms
• Voltage level: 5V TTL

Power supply

• Voltage: 110 or 240 VAC
• Frequency: 50 Hz or 60 Hz Power: 60 W

Environmental specifications

• Operating temperature: 0C to 40C
• Relative humidity: Up to 90% non-condensing

Dimensions

• Height: 176 mm / 6.92 in (4RU)
• Width: 430 mm / 19.92 in (for 19 rack)
• Depth: 300 mm / 11.81 in (not including connectors)
• Weight: 7.89 Kg
