The DmxMerger is a tool for combining signalsfrom multiple lighting controllers into a single DMX network. Up to six different DMX signalscan be merged together.How the DMX signals are merged togetherdepends on the merging strategy. The Dmx Merger offers three different strategies amongst its six inputs: LTP, HTP and Priority.The Latest Takes Precedence strategy selects one of the LTP inputs based on which port hadthe most recent change. This can be a change in channel levels or a DMX signal becoming active.The Highest Takes Precedence strategy is used for combining the HTP inputs and the result ofthe LTP merging. In this strategy each DMXchannel is compared across the inputs and thehighest value is forwarded to the output.If a DMX signal is present on the Priority inputthen this input is forwarded directly to theDmxMergers output. In this case all otherinputs are ignored.Specifications

• DIN Rail mounting
• DMX512-A (ANSI E1.11)
• Priority, HTP & LTP merging
• Screw terminals
• 6 Inputs
• Optical Isolation (individual per port)
• 9-24V DC 500mA (PSU optional)
• Operating temperature -20C to+50C (-4F to 122F)
• Compliance EN55103-1 EN55103-2

Dimensions

• Width: 104mm (4.09 inch)
• Height: 105mm (4.13 inch)
• Depth: 29.5mm (1.16 inch)
