TheCueCore3fromVisual Productionsis a compact, yet sturdy multi-protocol DMX lighting controller designed for professional and architectural use. This standalone, four-universe lighting interface is completely solid-state with no moving parts, providing users with secure and low-maintenance operation.
The onboard flash memory allows you to record and store up to 6GB of DMX shows. Fully automated playback is supported, but it can also be triggered by several IP-based protocols, including GPI, MIDI, or an internal scheduler. The unit’s dynamic web interface will control a total of 2,048 channels.CueluxPro, vManager, and Kiosc software is bundled with the CueCore3.
Features
Specifications
| Inputs/Outputs | 4 xXLR 5-Pin (DMX) Female Input/Output 1 xXLR 3-Pin (SMPTE) 1 xDIN 5-Pin (MIDI) Female Input 1 xDIN 5-Pin (MIDI) Female Output 4 xGPI 1 xDC Barrel (Power) Input 1 xRJ45 (10/100 Ethernet) |
| Channels | 2048 |
| Power Source | AC Adapter |
| Protocol | ArtNet, DMX512, RDM, sACN, KiNET |
General
| Inputs/Outputs | 4 xXLR 5-Pin (DMX) Female Input/Output 1 xXLR 3-Pin (SMPTE) 1 xDIN 5-Pin (MIDI) Female Input 1 xDIN 5-Pin (MIDI) Female Output 4 xGPI 1 xDC Barrel (Power) Input 1 xRJ45 (10/100 Ethernet) |
| Channels | 2048 |
| Dimming | Optional |
Power
| Power Source | AC Adapter |
| DC Input Power | 9 to 24 VDC at 500 mA |
| PoE Port Power | Yes |
Compatibility
| Protocol | ArtNet, DMX512, RDM, sACN, KiNET |
Environmental
| Operating Temperature | -4 to 122F / -20 to 50C |
| Certifications | EN55103-1, EN55103-2 |
Physical
| Rack Mount | Yes |
| Dimensions | 6.6 x 3.9 x 1.6″ / 16.8 x 9.9 x 4.1cm |
