The Theatrixx Small Pack Series was developed to fulfill the needs of small installations of
rack mounted audio modules. The compact size of this two rackmount unit distribution
system and its reduced depth allows it to be installed at the bottom of an amplification rack
with minimal interference on internal hook-up. The front panel is cut from a thick 3/16″
aluminum sheet and is fixed to a robust steel chassis. This product can also be adapted for
other types of applications. This unit can be used in conjunction with the standard CD112A,
LD236A or any custom built distro with TL4 30A 120/240V outputs.

Specifications

Input

• Connector:L14-30 Flanged Inlet
• Breaker: No

Thru

• Connector:No

Outputs

• Connectors (Front Panel): 1x 5-20 Duplex
• Connectors (Back Panel)
  • 3x 5-20 Duplex
  • 2x L5-30 Receptacles
• Breakers
  • 4x 20A 120V Circuits
  • 2x 30A 120V Circuits

Features

• Breaker Protector: Yes
• Enclosure construction: Robust steel housing

Dimensions

• Height: 88.90 mm (3.50) 2RU
• Depth: 173.65 mm (6.84)
• Width: 482.60 mm (19.00)
