Digital Inputs and Outputs

• Connectors: XLR (AES/EBU) RCA Phono (SPDIF)
• Format: AES/EBU (24 bit), SPDIF (20 bit), EIAJ CP-340, IEC 958,
• Output Dither: HPF TPDF dither 8-24 bit
• Word Clock Input: BNC, 75 Ohm, 0.6 to 10 Vpp
• Sample Rates: 32 kHz, 44.1 kHz, 48 kHz
• Processing Delay: 0.5 ms @ 48 kHz
• Frequency Response DIO: DC to 23.9 kHz 0.01dB @ 48kHz

Sample Rate Conversion

• Type: Asychronous
• Dynamic Range: 120 dB
• THD+N: -106 dB 44.1 to 48 kHz @ 1 kHz, -2 dBFS
• Input Rate Range: 31 kHz to 49 kHz

Analog Inputs

• Connectors: XLR balanced (pin 2 hot)
• Impedance: 20 kOhm (balanced)
• Max. Input Level: +27 dBu (balanced)
• Min Input Level (for 0dBFS): -4 dBu
• A to D Conversion: 24 bit (1 bit, 128 times oversampling)
• A to D Delay: 0.8 ms @ 48 kHz
• Dynamic Range: >103 dB (unweighted), >106 dB (A)
• THD: -95 dB (0.018%) @ 1 kHz -6 dBFS (FS@ +18 dBu)
• Frequency Response: 10 Hz to 20 kHz: +0/-0.2dB
• Crosstalk: <-80 dB, 10 Hz to 20 kHz typical -100 dB @ 1 kHz

Analog Outputs

• Connectors: XLR balanced (pin 2 hot)
• By-pass: Through relay
• Impedance: 40 Ohm (balanced)
• Max. Output Level: +26 dBu (balanced)
• Full Scale Output Range: -4 dBu to +26 dBu (balanced)
• D to A Conversion: 24 bit (1 bit, 128 times oversampling)
• D to A Delay: 0.57 ms @ 48 kHz
• Dynamic Range: >100 dB (unweighted), >104 dB (A)
• THD: -86 dB (0.005%) @ 1kHz, -6 dBFS (FS @ +18 dBu)
• Frequency Response: 10 Hz to 20 kHz: +0/-0.5 dB
• Crosstalk: <-60 dB, 10 Hz to 20 kHz typical 90 dB @ 1kHz

EMC

• Complies with: EN 55103-1, EN 55103-2 FCC part 15, Class B CISPR 22, Class B

Safety

• Certified to: IEC 65, EN 60065, UL 1419 and CSA E65

Environment

• Operation Temperature: 32 F to 122 F (0 C to 50 C)
• Storage Temperature: -22 F to 167 F (-30 C to 70 C)
• Humidity: Max. 90% non-condensing

PCMCIA Interface

• Connector: PC Card, 68 pin type 1 cards
• Standards: PCMCIA 2.0, JEIDA 4.0
• Card Format: Supports up to 2 MB SRAM

Control Interface

• RS485/RS422: 5 Pin DIN
• MIDI: In/Out/Through: 5 Pin DIN
• GPI, Pedal, Fader: 1/4 inch phone jack

General

• Finish: Anodized aluminum face and top plate Plated and painted steel chassis
• LCD: 56 x 128 dot graphic LCD-display
• Mains Voltage: 100 to 240 VAC, 50 to 60 Hz (auto-select)
• Power Consumption: <20 W
• Backup Battery Life: >10 years
• Dimensions: 19″ x 1.75″ x 8.2″ (483 x 44 x 208 mm)
• Weight: 5.2 lb. (2.35 kg)
