Combining professional-quality monitoring control and headphone amplification with hi-fi DAC and 120V technology, thePhonitor 3 DACfromSPLis the ideal centerpiece for any audio monitoring solution. With Phonitor 3 you get the same monitoring quality as the big SPL mastering consoles, but with the added benefit of spatial perception of the stereo image for perfect headphone mixing, avoiding the tendency for headphone mixes to differ greatly from their playback on loudspeakers.
The Phonitor 3 sports a high-quality AKM4490 DAC and the op-amp-based SLP120 low-pass filter for the finest digital and analog audio details. Combined with versatile I/O ranging from analog XLR to digital AES, S/PDIF, and USB connections, you can achieve a blistering, high sample rate of 32-bit / 768 kHz and DSD256 effortlessly. And with 120V technology, the Phonitor 3 delivers greater headroom, dynamic range, and sound quality compared with your average DAC. The Phonitor 3 includes a 19″, 2 RU rack expansion with extra connections for up to four stereo speaker pairs and a power cord.
Excellent Sound for Headphones
The Phonitor 3 DAC offers connection for a standard pair of headphone with a stereo 1/4″ jack on the front. Thanks to the enormous output power, all kinds of headphones can be driven effortlessly.
Excellent Sound for Loudspeakers
On the rear of the device, Phonitor 3 DAC offers a stereo output, which makes it a high-quality monitoring controller for any situation. Active speakers with an integrated power amplifier, or passive speakers in combination with a power amplifier can be connected at this output.
Monitor at The Highest Level
Phonitor 3 DAC offers the same key technologySPL 120V technologyand signal quality as the big SPL DMC and MMC mastering consoles.
Digital and Analog Stereo Inputs
Up to six stereo sources can be connected to the Phonitor 3 DAC. Use the Source switch to select between two different XLR stereo pairs, USB, coaxial S/PDIF, optical S/PDIF, and digital XLR AES input.
Analog InputsOn the analog side, two analog stereo inputs are offered, each with two XLR line inputs. Professional analog players with balanced line-level outputs can be connected here.
Features
Specifications
| Number of Headphone Channels | Single Channel |
| Recommended Headphone Impedance | Not Specified by Manufacturer |
| Headphone Output Power | 5 W per Side into 250 Ohms 1 W per Side into 32 Ohms |
| Analog Audio I/O | 4x XLR 3-Pin Balanced Mono Line Input (2 StereoPair, Rear Panel) 2x XLR 3-Pin Balanced Mono Monitor/Speaker Output (1 StereoPair, Rear Panel) 1x 1/4″ TRS Stereo Headphone Output (Front Panel) |
| Digital Audio I/O | 1x XLR 3-Pin AES3 Input 1x RCA Coaxial S/PDIF Input 1x TOSLINK Optical S/PDIF Input |
| USB I/O | 1x USB-B (Digital Input) |
| Wireless | No |
| Frequency Response | Headphone, Analog: 10 Hz to 100 kHz |
| Power Requirements | AC Input |
| Number of Headphone Channels | Single Channel |
| Recommended Headphone Impedance | Not Specified by Manufacturer |
| Headphone Output Power | 5 W per Side into 250 Ohms 1 W per Side into 32 Ohms |
| Digital Chipset | DAC: 1 x AKM AKM4490 Velvet Sound |
| Analog Circuitry | Low-Pass Filter Op-Amp: SPL120 |
| EQ | No |
| Display | 2x VU Meter (Backlit) |
Connectivity
| Analog Audio I/O | 4x XLR 3-Pin Balanced Mono Line Input (2 StereoPair, Rear Panel) 2x XLR 3-Pin Balanced Mono Monitor/Speaker Output (1 StereoPair, Rear Panel) 1x 1/4″ TRS Stereo Headphone Output (Front Panel) |
| Digital Audio I/O | 1x XLR 3-Pin AES3 Input 1x RCA Coaxial S/PDIF Input 1x TOSLINK Optical S/PDIF Input |
| USB I/O | 1x USB-B (Digital Input) |
| Wireless | No |
Performance
| Frequency Response | Headphone, Analog: 10 Hz to 100 kHz |
| Gain/Trim Range | -97 dB to +0 dB |
| Maximum Input Level | 32.5 dBu |
| Maximum Output Level | 32.5 dBu |
| Dynamic Range | 134.5 dB |
| Impedance | Inputs: 22 Kilohms Outputs: 75 Kilohms |
| THD+N | XLR Analog: 0.0009% (Balanced, 0 dBu, 1 kHz) 1/4″ Analog: 0.0003% (Headphones, 0 dBu, 1 kHz) |
| Noise | -102 dBu (A-Weighted) |
| CMRR | -82 dB |
| Crosstalk | XLR Analog: -95 dB (at 1 kHz) 1/4″ Headphone Outputs: -91 dB (at 1 kHz) |
| Damping Factor | 1/4″ Headphone Outputs: 180 at 40 Ohms |
Digital Audio
| Sample Rates | XLR AES3 Inputs: 44.1 to 192 kHz (PCM) RCA Coaxial S/PDIF Input: 44.1 to 192 kHz (PCM) TOSLINK Optical S/PDIF Input: 44.1 to 192 kHz (PCM) Input: 44.1 to 768 kHz (PCM) Input: Up to 11.2 MHz (DoP (DSD over PCM)) |
| Bit Depths | 32-Bit (PCM) |
Compatibility
| OS Compatibility | macOS Windows |
| Supported Drivers/API & Plug-Ins | macOS Class-Compliant (No Driver Needed) |
| Mobile App Compatible | No |
| Mobile Device Compatibility | No |
| Required Hardware | USB Cable |
Power
| Power Requirements | AC Input |
| Rail Voltage | Op-Amp: 60 V |
| AC Input Power | User Selectable: 115 to 230 VAC, 50 / 60 Hz (T 1 A) |
| Ground Lift | No |
| AC/DC Power Adapter | No |
| Power Consumption | 40 VA |
Physical
| Rackmount Size | 2 RU (with Included Hardware) |
| Dimensions | 11.78 x 11 x 4″ / 29.92 x 27.9 x 10.2cm (with Feet) |
| Weight | 9.1lb / 4.1kg |
