Control your display with the PresenStationTM 800 F1 4K interactive podium without having to turn your back on your audience.

Write, draw, and annotate on your documents, slides, and desktop with our fast electromagnetic pen technology that simulates writing on paper.

Features

• Multiple connection ports
• Pressure sensitive touch
• Universal VESA mount
• Intuitive capacitive touch

Specifications

• Panel Type Active-Matrix Liquid Crystal Display (TFT)
• Effective Screen Size 23 inch 20.75(H) 11.67(V) inches
• Resolution 3840(H) 2160 (V)
• Color Support 1.07B
• Brightness 300 cd/m2
• Surface Anti-Glare
• Viewing Angle 178 (H), 178 (V)

Writing Characteristics

• Touch Technology 10-points Capacitive Touch and Electromagnetic Pen Touch
• Pen Battery-less Passive Pen PA2
• Tablet Resolution 5080Lpi
• Pen Pressure 8192 Levels
• Reading Accuracy 0.5 mm (center)
• Tracking Approximately 220 points per second
• Capacitive Touch 14 ms speed, 10 point touch

Ports

• Inputs HDMI, USB Type C, USB Type A (3.0) x 3, USB Type B (3.0), 12v DC Power
• Outputs HDMI 1

Physical Specs

• External Dimensions 517 (W)321.8 (H)30 (D) mm (without stand)
• Stand Adjustment Adjustable in the range of 12 to 130
• CompatibleOperating Systems Windows 10 or above, Mac 10.9 or above or Chrome OS
