140-Watt powered guitar amp speaker cabinet optimized to work seamlessly with Spark, Spark MINI and Spark GO amps, as well as other modelers, instruments or amps. Versatile, high-quality sound for live performances, recording sessions and home practice.

Spark CAB is compact enough to fit anywhere with high-qualitysound big enough to blow the doors down.Live performances. Recording sessions. Home practice. CAB has you covered.

Power player.

Spark CAB features a 10-inch woofer and 2 high-frequency dome tweeters, powered by a built-in 140-Watt Class D amplifier. Getclear and accurate dynamic sound reproduction,with full range flat response (FRFR).

Outsized performance.

Withplenty of power and headroom,CAB delivers authentic feel and high volume output. Precise and transparent audio reproduction allows players to hear every nuance, capturing the intricate details of every guitar tone.

Built To perform.

Crafted for guitarist who crave reliability and style as much as sonic excellence. Spark CAB achieves this, equally at ease on stage and in your living room.

SPECIFICATIONS

AUDIO SPECIFICATIONS

FREQUENCY RANGE

• 45-20,000 Hz
• STEREO/MONO
• MONO

MAXIMUM SOUND PRESSURE LEVEL

• 117 dB (RMS), 120 dB (Peak)

CABINET PRINCIPLE

• Bass Reflex

POWER AMPLIFIERS

• 140 Watt Class D Amplifier

SPEAKERS

• 1×10-inch woofer, 2×1-inch (25mm) tweeter

TOTAL IMPEDANCE

• 4 ohms

CONTROLS AND CONNECTIVITY

BACK PANEL CONTROLS

• Input Selector – Switch between the 3.5 mm Spark Input and the two mono XLR/TRS Combo Inputs
• Speaker Volume
• Line Out Volume
• Ground Lift Switch
• Contour Switch – Boosts low and high frequencies to improve balance at low volumes

WIRED CONNECTIVITY

• 1 x 1/8″ dedicated stereo Input for Spark Amp
• 2 x mono XLR/TRS combo inputs
• 1 x mono XLR balanced output

PHYSICAL UNIT

DIMENSIONS

• 492.5 x 399.8 x 255 mm (with rubber feet) (19.39 x 15.74 x 10.04 in)

WEIGHT

• 13.5 kg
• 29.76 lbs

GRILLE CLOTH

• Woven

Handle

• 2 recessed speaker handles on the sides

Cable Tie

• 1 adjustable cable tie for fixing instrument and audio cables on the back

INCLUDED IN THE BOX

BOX CONTENTS

• 3.5mm stereo audio cable for Spark amps
• DC power cable for Spark
• Power cord
• Quick Start Guide
• Safety Instructions Card

POWER

MAIN INPUT POWER

• AC 100-240V

DC POWER OUTPUT For Spark

• DC 19V/2.5A

USB-C POWER OUTPUT For Spark MINI & GO

• DC 5V/2A
