15A 125V Locking Flanged Inlet – White Body in a Black Housing
Specifications
| Item | Flanged Inlet, locking |
| Rating | 15 amperes, 125 volts, NEMA Configuration L5-15P |
| Materials | Device body and flange are nylon with CTI greater than 600 volts. Blades are solid brass, 0.060″ thick. |
| Terminals | Tempered brass, lug style, Perma-Lock design. Terminals visible through clear end cap. |
| Terminal Identification | Terminal screws are color coded. Ground wire entrance hot stamped green and marked “GR.” Line wire entrance hot stamped black. |
| Listings | UL listed, File E57672 CSA certified, File LR81290 |
| Dimensions | 2.57″ x 2.57″ x 1.87″ |
