15A 120V IEC 320 Specification Grade Connector
Specifications
| Item | Connector, appliance coupler. IEC 60320 standard sheet C13. |
| Rating | For cold conditions (70C rating). 10 amperes, 250 volts ac: International. 15 amperes, 250 volts ac (max): North America. |
| Materials | Plastic parts are heat stabilized nylon with CTI greater than 400 volts. Contacts are solid brass |
| Contacts | One piece, .032″ thick brass, double wipe |
| Terminals | Tempered brass, lug style, Perma-Lock design. |
| Terminal Identification | Terminal screws are color coded. Wire entrance holes marked L, N. |
| Cord Clamp | Internal. Accommodates 0.300″ (18/3 SJ) to 0.655″ (12/3 S) North American cable, and 3 conductor .75 to 4.00 mm harmonized cable |
| Overall Design | Two assembly screws, U-drive style. All screws are combination slot/cross head. Beveled housing. Dust seal at cord entry. Cable strip length gauge molded into connector body. |
| Listings | UL listed, CSA certified. |
