30A 125V Standard NEMA Locking Plug
Specifications
| Item | Plug, locking. |
| Rating | 30 amperes, 125 volts, single-phase, 2-pole, 3-wire |
| Configuration | NEMA L5-30P |
| Materials | Housing and plug body are nylon with CTI greater than 600 volts |
| Terminals | Clamp-type, with color-coded brass terminal screws, 10-32 |
| Blades | Blades are solid brass 0.070″ thick |
| Cord Clamp | Internal, with removable insert to accommodate cable from .325″ (16/3 SJ) to .720″ (10/3 S). |
| Overall Design | Three assembly screws, U-drive style. All screws are combination slot/cross head. Dust seal at cord entry. Beveled housing. |
| Certifications | UL listed, File E57672 CSA certified, File LR81290 |
| Dimensions | 2.54″ x 1.84″ x 1.84″ |
