Delivering power and durability, theF388-2-Q 4-Channel Headphone AmpfromLake Peopleis a versatile, rack-mountable studio headphone and speaker amplifier, providing 4-channels of low-noise amplification for headphones between 16 and 600 ohms as well as stud
Delivering power and durability, theF388-2-Q 4-Channel Headphone AmpfromLake Peopleis a versatile, rack-mountable studio headphone and speaker amplifier, providing 4-channels of low-noise amplification for headphones between 16 and 600 ohms as well as studio monitors and loudspeakers. Ultralow-impedance amplifier outputs ensure optimal performance with the lowest impedance headphones, and pre-gain can be set internally between -12 and +12 dBr for refinement when matching to your preferred listening device.
The F-388 comes with four balanced XLR inputs (left and right), four stereo 1/4″ headphone outputs, and four stereo 1/4″ line outputs. Each channel sports dedicated volume and balance adjustment knobs and the unusually high internal operating voltage ensures a more than adequate sound level is maintained, even when used with very-high-impedance headphones.
Specifications
| Number of Headphone Channels | 4-Channel |
| Recommended Headphone Impedance | 16 to 600 Ohms |
| Headphone Output Power | 425 mW into 600 Ohms 800 mW into 300 Ohms 2250 mW into 100 Ohms 1620 mW into 50 Ohms 1100 mW into 32 Ohms 490 mW into 16 Ohms |
| EQ | No |
| Display | No |
Connectivity
| Analog Audio I/O | 4 xXLR 3-Pin Balanced Line Input (1 StereoPair, Rear Panel) 4 x1/4″ TRS Stereo Headphone Output (Front Panel) 4 x1/4″ TRS Stereo Line Output (Rear Panel) |
| Digital Audio I/O | No |
| Network I/O | No |
| USB | No |
Performance
| Frequency Response | 5 Hz to 50 kHz -0.5 dB |
| Maximum Output Level | 1/4″ Headphone Outputs: 2.25 V (Into 100 Ohms) |
| Impedance | 10 Kilohms |
| THD+N | < 0.002% (At -1 dBFs) |
| SNR | > 120 dBA |
| Crosstalk | < -80 dB |
Power
| Power Requirements | AC Input |
| AC Input Power | 115 to 230 VAC, 50 / 60 Hz (T .25 A) |
| Ground Lift | Yes |
| AC/DC Power Adapter | No |
| Power Consumption | 15 VA |
Physical
| Rackmount Size | 1 RU |
| Dimensions | 19 x 6.5 x 1.7″ / 48.3 x 16.6 x 4.4cm |
Packaging Info
| Package Weight | 7.205 lb |
| Box Dimensions (LxWxH) | 21.4 x 10.7 x 5″ |
