KD-X444LP is a 4K/UHD 18Gbps, HDCP2.2 compliant HDMI over CAT6 Transmitter Plus Receiver. The HDMI extender set extends HDMI signals with the latest standards in resolution, HDR, and Chroma over a single CAT6 cable.

Easily Select HDMI Resolution and Audio Format

Extended Display Identification Data (EDID) plays a crucial role in HDMI handshaking. It enables the display to communicate its capabilities to the connected source.

The KD-X444LP HDMI extender set provides 16 options for EDID handshake, including an auto feature that adapts to display capabilities. This ensures compatibility and reliable video and audio transmission all part of Key Digital’s HDMI proprietary Full Buffer Technology.

Forced Hot Plug Detection: Troubleshooting Made Easy

Forced Hot Plug Detection ensures the display recognizes the source, eliminating signal loss issues in complex setups. This simple tool streamlines troubleshooting and reduces sync times during system startup.

Long-Range Performance

The KD-X444LP is designed for long-range applications. It extends signals up to 230 feet (70 meters) or greater when using CAT6 cable. With the HDMI pass-through port on the transmitter, you can easily add monitors near the source location. This is ideal for presentations, dual display systems, or connection to AV surround receivers.

Additionally, KD-X444LP supports 3.5mm IR and RS-232 control, enhancing its integration with connected AV equipment over a single CAT6 cable.

The kit includes an IR sensor, emitter, and a single power supply thanks to flexible Power over CAT (PoC) technology. You may connect the power supply to the unit most convenient for your installation.

Universal Shelf Mount Solution (KD-SMS16)

Key Digital also offers theKD-SMS16, a shelf-mount solution compatible with the KD-X444LP. This versatile mounting option provides a clean, professional look for installations. Visit ourwhere-to-buypage to get this product.

Features

• Single CAT5e/6 UTP/STP Extension:Fully automatic equalization, and amplification depending on cabling length
• 4K Resolution Support:4096×2160 or 3840×2160 24/25/30/60hz at 4:4:4 (signals up to 18Gbps bandwidth)
• Flexible Power over CAT (PoC):Only one power connection needed. Tx may power Rx, or Rx may power Tx
• Low Profile:Super slim chassis design
• Signal Extension:4K/UHD (18G) up to 230ft / 70m with CAT5e/6, up to 328ft / 100m with CAT6A STP. 1080p up to 230 ft / 70m with CAT5e/6, up to 328ft / 100m with CAT6A STP
• IR Sensor:Sensor powering via +5V on IR In ports collects line-of-sight IR from remote(s) without external IR connecting block
• Up/Down IR:Two channels of IR enable control to/from devices or control systems connected to Tx and Rx units
• RS-232:Bi-Directional control to/from Tx and Rx unit on Phoenix connector
• Surround Audio Support:HDMI Pass-Thru supports Dolby, Dolby TrueHD, DTS and DTS-HD (formats up to 7.1); CAT6 Output supports Dolby, DTS (formats up to 5.1/6.1)

Specifications

• Inputs Tx (Each): 1 HDMI, 1 IR, 1 RS-232
• Outputs Tx (Each): 1 CAT6/6A, 1 HDMI pass-through, 1 IR, 1 RS-232
• Inputs Rx (Each): 1 UHDoTP, 1 IR, 1 RS-232
• Outputs Rx (Each): 1 HDMI, 1 IR, 1 RS-232
• Bandwidth: TMDS bandwidth 18Gbps
• Deep Color Support: Digital video formats in Deep Color Mode up to 12 bits per color
• DDC Communication: EDID and HDCP Bi-directional buffering from Display to Source
• HDMI Connector: Type A, 19 Pin Female
• RJ45 Connector: Shielded Link Connector, Proprietary TMDS, IR, RS-232 extension technology
• IR In & Out Connectors (Each): 3.5mm
• RS-232 Connector: 3-pin phoenix
• Power: (1) 12V/2A, 24W DC Power Supply (Screw-In Type). 100-240VAC, 50-60Hz. Interchangeable transformer plug with screw-in connector. SKU: KD-PS12V2ASC. <12W power consumption.

General

• Regulation: CE, RoHS, WEEE, EAC
• Enclosure: Black Metal
• Product Dimensions (ea) (LxWxH): 4.3 x 4.12 x 0.82 (109.2 x 104.6 x 20.8mm)
• Product Weight (ea): 0.595 lbs (0.27 KG)
• Package Dimensions (LxWxH): 10.24 x 5.67 x 3.15 (260 x 144 x 80mm)
• Package Weight: 2.34 lbs (1.06 KG)
