iFi Audio NEO IDSD2 Lossless Bluetooth DAC and Headphone Amplifier

$100.00 $1,086.99

Its head-fi. Its desk-fi. And its hi-fi.The NEO iDSD 2 is aversatile 3-in-1 DAC/Ampdesigned for CAS audiophiles. It works as aHead-Fi DAC/Amp with headphones, a pure DAC with an integrated amp, or a DAC/Preampfor active speakers and power amps. Equipped wi

Qty:

Payment:

Payment Option Image

Its head-fi. Its desk-fi. And its hi-fi.

The NEO iDSD 2 is aversatile 3-in-1 DAC/Ampdesigned for CAS audiophiles. It works as aHead-Fi DAC/Amp with headphones, a pure DAC with an integrated amp, or a DAC/Preampfor active speakers and power amps. Equipped with Bluetooth 5.4,it supports aptX Lossless,the only Bluetooth codec that streams CD-quality audio without quality loss.

Its new and Lossless.

The NEO iDSD 2, powered byQualcomms new QCC518x Bluetooth chipand qualified for Bluetooth 5.4, supports all major Bluetooth formats:aptX Lossless, aptX Adaptive, aptX, LDACTM, LHDC/HWA, AAC, and SBC.With aptX Lossless,it offers an impressive 1,200kbpsbitrate, streaming true CD-quality audio without lossy compression, ensuring a superior listening experience.

Stand by you. No matter up or down.

TheNEO iDSD 2 offers versatile positioning for Desk-Fi or Hi-Fi setups, with a 2-inch color display that automatically rotates to match horizontal or vertical orientation.For Desk-Fi, you can position it vertically to save space. The NEO iDSD 2 also features an analogue volume control, delivering higher audio quality than digital controls.

GMT Femto-Precision Clock. Upgradable.

The NEO iDSD 2 features an internal GMT femto-precision clockwith a smart storage cache,creating an advanced jitter reduction system for cleaner, more accurate sound.For those with an external clock, the 10MHz External Sync Clock input allows you to synchronize the NEO iDSD 2 with other devices like CD players or network streamers, enhancing clock signal accuracy.

This rare feature in its price range ensures exceptional performance, whether using the internal clock or an external sync clock.

More than new features. Enhanced circuitry.

TheNEO iDSD 2s enhanced PureWave circuit design features a balanced dual-mono topologyand short signal paths, ensuring superb linearity, low noise, and minimal distortion.

This results in an impressive SNR >120dB(A), DNR of -120dB(A), and THD+N <0.0015%, achieving performance comparable to higher-priced DACs.

With a maximum headphone output power of 5,551 mW (@ 32), it outperforms even some dedicated headphone amplifiers, making them sweat. It features Auto iEMatch to reduce annoying hiss from high-sensitivity headphones without losing any dynamic range

The NEO iDSD 2 is not only a powerhouse, but its also tailored for your ears. The newly added analogue processing modes, XSpace and XBass II, along with the four digital filters, allow you to finetune the sound.

Specifications

BLUETOOTH FORMATS Bluetooth 5.4 (aptX Lossless, aptX Adaptive, aptx, LDAC, HWA/LHDC, AAC and SBC)
DIMENSIONS 214 x 158 x 41 mm (8.4″ x 6.2″ x 1.6″)
DNR Line Section

  • >120dB(A) @ -60dBFS

Headphone Section

  • -120dB(A)
FORMATS SUPPORTED PCM 768kHz; DSD 512 (22.6MHz); MQA Full Decoder
INPUT USB3.0 B (USB2.0 compatible); S/PDIF (coaxial up to 192kHz, optical up to 96kHz)
LIMITED WARRANTY 12 months**
MAXIMUM OUTPUT POWER Headphone Section

    • Balanced:>19.5V/650 mW (@ 600); >13.3V/5,551 mW (@ 32)
    • UnBAL:>10.5V/184 mW (@ 600); >9.5V/2,832 mW (@ 32)
    NET WEIGHT 916g (2.0 Ibs)
    OUTPUT Line Section

      • Outputs:
      • Balanced XLR: 19.5V max. (variable) 4.4V fixed
      • UnBAL RCA: 10.5V max. (variable) 2.2V fixed

    Headphone Section

      • Outputs:
      • Balanced 4.4mm: 3.5V / 19.5V max. (12 – 600 Headphone)
      • UnBAL 6.3mm: 4.5V / 9.50V max. (12 – 300 Headphone)
    OUTPUT IMPEDANCE Line Section

    • XLR 100; RCA 50

    Headphone Section

    • <1
    POWER CONSUMPTION No Signal ~5W; Max Signal ~13.5W
    RMS OUTPUT POWER Headphone Section

      • Balanced:>19.3V/620 mW (@ 600); >12.7V/2530 mW (@ 64)
      • UnBAL:>9.7V/157 mW (@ 600); >9.4V/1390 mW (@ 64)
      SNR Line Section

      • <-120dB(A) @ 0dBFS

      Headphone Section

      • >120dB(A) (3.3V 6.3mm/6.2V 4.4mm)
      THD+N Line Section

      • <0.0015% @ 0dBFS

      Headphone Section

      • <0.0015% (125mW @ 32)
