Locking Devices, Twist-Lock, Industrial, Flanged Receptacle, 30A 125/250V, 3-Pole 4-Wire Grounding, L14-30R, Screw Terminal, WhiteFeaturesBackwired terminations for ease of installation#10-32 Multiple drive terminal screws (Slotted, Phillips, Robertson)Mou
Locking Devices, Twist-Lock, Industrial, Flanged Receptacle, 30A 125/250V, 3-Pole 4-Wire Grounding, L14-30R, Screw Terminal, White
Features
Specifications
| Application | Heavy Duty Industrial |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| Horsepower – Maximum | 2(2) |
| Item Type | 30A Grounding Insulgrip Flanged Receptacle |
| Material | Nylon |
| Material – Mounting Hardware | Screw Mounting |
| Number Of Poles | 3-Pole |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Performance |
|
| Type |
|
| UPC | 783585039213 |
| Dimensions | 3.06 in x 3.06 in x 2.27 in |
| Display Size | Standard Sized Product |
| Height | 2.27 in |
| Length | 3.06 in |
| Weight | 0.35 lb |
| Width | 3.06 in |
| Amperage Rating | 30 A |
| Connectivity | Back Wired Screw Terminals |
| Current / Amperage Rating | 30 A |
| Current Rating | 30 A |
| Dielectric Strength | Withstands 2,000V minimum |
| Phase | Single Phase |
| Voltage Rating | 125/250 VAC |
| Voltage Rating Description | 125/250 VAC |
| Number Of Wires | 4-Wire |
| Wire Size | #16 AWG to #8 AWG |
