Locking Devices, Twist-Lock, Industrial, Male Insulgrip Plug, 20A 250V AC, 2-Pole 3-Wire Grounding, NEMA L6-20P, Screw Terminal, Black and White Nylon.
Features
- Ribbed nylon housing provides a secure grip and impact and chemical resistance.
- Superior cord grip design protects terminations from excess strain.
- Clear, funnel shaped wire entry for ease of termination.
- Integral dust shield protects wiring chamber from dust or contaminants.
Specifications
| Application |
Extra Heavy Duty Industrial |
| Color |
Black, White |
| Cord Range |
0.360″-0.930″ (9-24) |
| Environmental Conditions |
Indoor Dry Unless Protected By Additional Means |
| Horsepower – Maximum |
2 |
| Item Type |
20A Male Insulgrip Plug |
| Material |
Nylon |
| Material – Mounting Hardware |
Cord Mounted |
| Number Of Poles |
2-Pole |
| OEM Brand Name |
Hubbell Wiring Device-Kellems |
| Operating Temperature |
Maximum continuous 75C and minimum -40C without Impact |
| Performance |
- Electrical – Current Interrupting – Certified for current interrupting at full rated current
- Electrical – Dielectric Voltage – Withstands 2,000V minimum
- Environmental – Flammability – HB or better per UL94 or CSA 22.2 No. 0.6
- Environmental – Moisture Resistance – IP20 Suitability
- Environmental – Operating Temperatures – Maximum Continuous 75C Minimum -40C (w/o impact)
- Mechanical – Terminal Accommodation – #16 AWG – #8 AWG stranded copper wire only.
- Mechanical – Terminal Identification – Terminals identified in accordance with UL 498
|
| Type |
|
| UPC |
783585037820 |
Dimensions
| Dimensions |
2.26 in x 2.26 in x 2.75 in |
| Display Size |
Standard Sized |
| Height |
2.75 in |
| Length |
2.26 in |
| Weight |
0.20 lb |
| Width |
2.26 in |
Electrical Ratings
| Amperage Rating |
20 A |
| Connectivity |
Pressure Terminal Screws |
| Current / Amperage Rating |
20 A |
| Current Rating |
20 A |
| Dielectric Strength |
Withstands 2,000V minimum |
| Phase |
Single Phase |
| Voltage Rating |
250 VAC |
| Voltage Rating Description |
250 VAC |
Conductor Related
| Cable Range |
0.360 – 0.930 in |
| Cord Type |
All Listed Portables |
| Number Of Wires |
3-Wire |
| Wire Size |
#16 AWG to #8 AWG |
Certifications and Compliance
| Industry Standard(s) |
- Certified to CSA C22.2 No.42
- Fed.Spec. W-C-596
- Listed to UL 498
|
| Nema Rating |
L6-20P |
| Standards – RoHS Compliance Status |
CM |
