The next chapter in a legendary career of guitar innovation, the Deluxe Bobby Weir 3 is a masterful semi-hollow offering a huge variety of unique tones. Pairing a sleek body shape with two custom TV Jones humbuckers and a wiring configuration that allows a
The next chapter in a legendary career of guitar innovation, the Deluxe Bobby Weir 3 is a masterful semi-hollow offering a huge variety of unique tones. Pairing a sleek body shape with two custom TV Jones humbuckers and a wiring configuration that allows access to inner and outer coil pairings via push-pull tone knobs, players can conjure Weirs notoriously slinky tones while also developing their own original sound. An ebony fingerboard caps a remarkably comfortable slim C-shape neck, while a smooth neck transition and deep cutaway allow for easy access to higher frets. Additional premium features include Jescar fretwire, a custom DAngelico Shield tremolo, and locking tuners from Grover. Stage-tested with Dead and Company for years and designed to offer the perfect balance of airy warmth and Weir’s long-sought clang of cold steel, the Bobby Weir 3 is an undeniable tonal powerhouse.
ROAD-TESTED
After testing out countless prototypes on stage with Dead and Company as well as with Bobby Weir & Wolf Bros, the Deluxe Bobby Weir 3 is the culmination of more than five years of road-tested research and design, from small theaters to iconic stadiums to Weirs tour bus recording rig.
CUSTOM TV JONES PICKUPS
Custom DA-Trons from TV Jones are equal parts articulate and bold, offering a range of sounds from rich warmth to what Weir calls the clang of cold steel. And with a wiring configuration that allows players to isolate any coil across the set, the Bobby Weir 3 has no shortage of inspiring single-coil and blended tones.
STONE AND WINE
Available in two custom finishesWeirs original Matte Stone as well as an elegant Satin Trans Wine.
LIMITED EDITION
With only ten units hand-signed by Weir, the Deluxe Bobby Weir 3 is both a masterfully crafted instrument as well as a true collectors item. Each Limited Edition guitar includes a signed Certificate of Authenticity and Dead Forever memorabilia.
Specifications
HARDWARE | ||
Hardware Color | Gold | |
HEADSTOCK | ||
Headstock Shape | Standard | |
Logo Inlay | Mother of Pearl D’Angelico New York Logo | |
Series Inlay (Front) | Mother of Pearl Deluxe Shield Logo | |
Serial Number (Back) | Model Name, Serial Number | |
Binding | 3-ply | |
Finish | Satin | |
Headpin | Cupola | |
Tuners | Grover 509 Super Rotomatic, Locking | |
Strings | D’Angelico Electrozinc 10’s (10-46) | |
Truss Rod Cover | Skyscraper, Gold with Signature Engraved | |
Nut Width | 1 11/16″ | |
Nut Material | Graph Tech Tusq | |
FINGERBOARD | ||
Material | Ebony | |
Binding | 3-ply | |
Fretwire | Jescar 47/104 Nickel Silver | |
Scale Length | 25″ | |
Radius | 16″ | |
Top Inlay | Mother of Pearl Split Block | |
Side Marker | Yes | |
Fret Number | 22 | |
NECK | ||
Material | 3 piece: Maple/Walnut/Maple | |
Finish | Satin | |
Profile | C-Shape | |
Joint Type | Set Neck | |
Thickness | 1F: 20mm, 12F: 22mm | |
Truss Rod | Dual Action | |
BODY | ||
Body Shape | Single Cutaway | |
Body Style | Semi-hollow (with centerblock) | |
Body Depth | 1.75″ | |
Body Width | 15″ | |
Color | Matte Stone | |
Finish | Satin | |
Top Material | Laminated Maple | |
Back Material | Laminated Maple | |
Side Material | Laminated Maple | |
Binding | 5-ply | |
Bridge | Gold Tune-O-Matic with Roller Saddles | |
Tailpiece | D’Angelico Shield Tremolo | |
Pickguard | Tortoise Scalini (5-ply) | |
Back Plate | N/A | |
Pickup Selector | 3-way Toggle | |
Knobs | 5 Ebony | |
Strap Buttons | Gold, Locking | |
ELECTRONICS | ||
Overview | 2 TV Jones Humbuckers | |
Controls | 2 Volume / 2 Tone (Push-Pull) / 1 Master Volume / 3-way Toggle Switch | |
Pickup (Neck) | TV Jones Custom DA’Tron (Neck) (Gold) | |
Pickup (Middle) | N/A | |
Pickup (Bridge) | TV Jones Custom DA’Tron (Bridge) (Gold) | |
Additional Pickup Info | N/A | |
Pots | 500k | |
Output Jack | Standard Mono | |
GENERAL | ||
Case | Deluxe Hardshell (DESSCASE) | |
Made In | Korea |
