HDBaseT 3.0 Transmitter/Receiver Set with USB 2.0

Specifications

• HDMI 2.0b and HDCP 2.2 compliant
• Supports 18Gbps video bandwidth
• Supports resolutions up to 2160p@60Hz(4K) 4:4:4
• HDR, HDR10, HDR10+, Dolby Vision LLM,
  and HLG pass through
• LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS,
  DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio,
  and DSD pass through
• Transmission distance up to 230ft/70m (4K30/1080P) or131ft/40m (4K60) via a single CAT6/6A cable
• Supports bi-directional POC (Power over Cable), when TX orRX gets power, the other end does not need an external powersupply
• Supports 3.5mm analog audio de-embedding at both transmitter and receiver ends
• Supports EDID management
• Supports bi-directional RS-232 signal pass-through,
  bi-directionalIR signal control, USB 2.0 signal transmission
• Compact design for easy and flexible installation
