Taking up little space only yet providing a powerful performance, the Cameo NANO Beam 600 is a miniature moving head providing 540 pan and 240 tilt. Equipped with a single 60 watt RGBW LED, it produces rich colour mixes and a tightly focussed 5.2 beam.

The compact luminaire offers 5 modes of DMX control. In addition, the NANO Beam 600 sports automatic operation and sound activation with stunning built-in programs, strobe and dimmer functions plus standalone and master/slave capability. A large TFT display with 4 control buttons permits easy menu navigation and configuration.

Made of hardwearing ABS and metal, the compound housing integrates a low-noise fan, IEC mains inlet and 3-pin DMX connectors. The NANO Beam 600 comes with an omega bracket providing multiple mounting options.

Features

• Miniature moving head with 17,500 lx illuminance @ 3m
• 60 W RGBW LED for a powerful output and rich colours
• 540 pan and 240 tilt
• Tightly focused 5.2 beam
• Dimming and strobe effects
• 5 modes of DMX control plus standalone, master and slave operation
• Large TFT display with 4 control buttons for intuitive operation
• Built-in microphone for sound activation
• Comes with omega bracket for multiple mounting options

Specifications

• Product type: LED Moving Lights
• Type: LED Moving Heads
• Colour spectrum: RGBW
• Number of LEDs: 1
• LED type: 60 W
• Dispersion: 5.2
• DMX input: XLR 3-pin male
• DMX output: XLR 3-pin female
• DMX mode: 12-channel, 14-channel, 3-channel, 5-channel, 8-channel
• DMX Functions: colour macro, Dimmer, PAN, Pan/Tilt Speed, RGBW, Show Mode, Strobe, TILT
• PAN movement: 540
• TILT movement: 240
• High Speed Strobe: 1 – 20 Hz
• Standalone modes: Auto programs, sound programs
• Controls: Enter, Mode, Value Down, Value Up
• Indicators: LC display
• Operating voltage: 100 V AC – 240 V AC, 50 – 60 Hz
• Power consumption: 65 W
• Fuse: F3AL / 250 V
• Power connector: IEC power connector male
• Housing material: ABS plastic, Metal
• Cabinet colour: Black
• Cooling: low-noise fan
• Illuminance: 157000 lx @ 1 m

Dimensions

• Width: 145 mm
• Height: 240 mm
• Depth: 155 mm
• Weight: 3 kg
