TheBose Videobar VB1is an all-in-one USB conferencing system offering high-quality audio and video in a sleek low-profile design for huddle rooms, offices, and medium-sized conference spaces. Thanks to the six beam-steering mics with automatic EQ and the 4K Ultra HD camera with autoframing, meeting participants can be clearly seen and heard.
The built-in stereo speaker system delivers plenty of power to fill the room with sound, whether it comes from your conference call or a mobile device connected via Bluetooth or the 3.5mm stereo aux input.
The Videobar VB1 integrates into existing networks for efficient setup and troubleshooting, and it can be conveniently controlled via your smartphone, a computer, or the supplied remote control. It includes a table stand and a wallmount kit for simple and flexible installation.
Features
Specifications
System Requirements | macOS 10.10 or Later
Windows 7, 8.1, or 10 Google Chromebook |
Microphone Setup
Microphones | 6 |
Frequency Response | 20 Hz to 15 kHz |
Pickup Range | 20′ / 6 m |
Beamforming | Static and Dynamic Adaptive Beamforming |
Noise Cancellation | Noise Suppression and Stereo Acoustic Echo Cancellation |
Speakers
Enclosure | Ported |
Number of Speakers | 2 |
Amplifier Power | 20 W per Channel |
Distortion | <0.3% over Frequency Response |
Maximum SPL | 89 dB SPL at 3.3′ / 1 m, IEC 60268-5 |
Frequency Response | 85 Hz to 20 kHz (-10 dB) |
Video
Supported Resolutions | UHD 2160p (4K), 1080p, 720p, 960 x 480, 848 x 480, 640 x 480, 640 x 360, 432 x 240 (30 fps) |
Encoding | H.264, M-JPEG |
Camera
Field of View (FOV) | Diagonal: 120 Horizontal: 109 Vertical: 67 |
Sensor | 8 MP, 4K Resolution |
Digital Zoom | 5x |
Focus Distance | 1.6′ / 0.5 m to Infinity |
UVC Video Class | v1.1 |
White Balance | Automatic |
Brightness Control | Automatic |
I/O
USB Connectors | 1 x USB 3.0 Type-C 1 x USB 3.0 Type-A |
HDMI Connector | 1 x HDMI 1.4 Type-D |
Audio Input | 1 x 1.8″ / 3.5 mm TRS |
Ethernet | 1 x RJ45 |
GPI | 1 x 2-Pin Euroblock |
Communications
Ethernet Specifications | IEEE 802.3 |
Wi-Fi Standard | 802.11ac (Wi-Fi 5) |
USB Specifications | USB 3.0 UAC, UVC, HID |
Bluetooth Version | 4.2 |
Bluetooth Profiles | HSP, A2DP, AVRCP, BLE |
Display | DisplayLink |
Regulatory
Safety | IEC/UL/EN 60065:2014/A11:2017, IEC/UL/EN 62368-1:2014/A11:2017 |
EMC | FCC Part 15B Class B, ICES-003 Class B, CISPR 13, EN55032 Class B, EN55035, EN61000-3-2, EN61000-3-3, BSMI CNS13439 |
Wi-Fi | FCC Part 15C, RSS-GEN, RSS-247, RSS-102, EN300328, EN301893, EN301489 |
Environmental | RoHS |
Environmental
Operating Humidity | Up to 90% (Non-Condensing) |
Storage Humidity | Up to 93% Relative Humidity |
Storage Temperature | -40F to 158F / -40C to 70C |
Power
Power Supply Input | 110 to 240 VAC, 50/60 Hz, 1.5 A Max |
Power Supply Output | 24 VDC, 1.875 A |
Physical
Mounting | Table Stand (Included) Wall Mount (Included) Kensington Security Slot |
Dimensions | Videobar VB1: 1.9 x 27 x 3.8″ / 4.8 x 68.6 x 9.6 cm Remote Control: 0.7 x 1.9 x 4.9″ / 1.8 x 4.8 x 12.4 cm |
Weight | 5.6 lb / 2.5 kg |
Packaging Info
Package Weight | 11 lb |
Box Dimensions (LxWxH) | 29 x 5.7 x 5.5″ |
