Blustream HD12DB 1×2 4K HDMI Splitter With DTS Down Mixing

$99.00 $37,500.00

The Blustream HD12DB has been designed to convert and downmix embedded 5.1ch Dolby Audio or DTS Audio within a HDMI signal into a stereo 2ch signal available on HDMI, optical and analogue audio outputs.The HD12DB features a HDMI loop out to pass the origin

Qty:

Payment:

Payment Option Image

The Blustream HD12DB has been designed to convert and downmix embedded 5.1ch Dolby Audio or DTS Audio within a HDMI signal into a stereo 2ch signal available on HDMI, optical and analogue audio outputs.

The HD12DB features a HDMI loop out to pass the original video and multi-channel embedded audio signal to compatible equipment, with a second HDMI output featuring video scaling of resolutions up to 4K 60Hz 4:4:4 video to various lower video formats.

This provides the perfect cost effective solution for ensuring that 4K UHD video and multi-channel audio can be distributed around a multi-room system where there are a mixture of 2ch and 5.1ch zones with multiple output resolution requirements.

Features

  • Features an in-built DAC (Digital to Analogue audio Converter) that converts 5.1ch Dolby Audio or DTS Audio to a stereo 2ch signal available on HDMI, optical and analogue audio outputs concurrently
  • Supports the following audio input formats: Dolby 5.1, DTS-ES 6.1, DD+5.1, DD+2.0, PCM 5.1, PCM 2.0 *
  • Features 1 x HDMI input supporting 4K UHD video (4K 60Hz 4:4:4) that is replicated to 2x HDMI outputs
  • HDMI loop out will replicate the HDMI input signal up to 4K 60Hz 4:4:4 and 5.1ch Dolby Audio & DTS Audio
  • HDMI audio breakout to downmixed analogue L/R audio and downmixed optical digital outputs concurrently
  • HDCP 2.2 compliant with advanced EDID management

HDMI output 2 features a video scaler allowing the output resolution to be set to the following formats:

  • 3840×2160@60Hz
  • 3840×2160@50Hz
  • 3840×2160@30Hz
  • 3840×2160@25Hz
  • 4K DCI@25Hz 4:4:4
  • 4K DCI@30Hz 4:4:4
  • 4K DCI@50Hz 4:4:4
  • 4K DCI@60Hz 4:4:4
  • 1920×1080@60Hz
  • 1920×1080@50Hz
  • 1280×720@60Hz
  • 1280×720@50Hz
  • 1920×1200@60Hz
  • 1680×1050@60Hz
  • 1024×768@60Hz

*NOTE: This product does not support decoding of DTS CD bitstreams. Playback of this format may produce undesirable noise.

Specifications

  • Video Input Connectors: 1 x HDMI Type A, 19-pin, female
  • Video Output Connectors: 2 x HDMI Type A, 19-pin, female
  • Audio Output Connectors: 1 x Optical (Toslink), 2x RCA analogue left / right
  • EDID: 4-pin DIP switch
  • Resolution: 4-pin DIP switch
  • Product Upgrade: 2 x Micro USB female
  • Dimensions (W x H x D): 127mm x 23mm x 104mm, without feet
  • Shipping Weight: 1.0kg
  • Operating Temperature: 32F to 104F (0C to 40C)
  • Storage Temperature: -4F to 140F (-20C to 60C)
  • Power Supply: 5V/3A DC

Box Contents

  • 1 x HD12DB
  • 1 x 5V/3A DC Power Supply
  • 1 x Mounting Kit
  • 4 x Rubber Feet
  • 1 x Quick Reference Guide
