TheWTSD-PWHUBis designed to be used in conjuction with AtlasIED WTSD wall plate mixers at the head-end (amp rack) in place of the WTSD-PWBOB when additional headroom control and external device integration is necessary. The WTSD-PWHUB provides an emergency audio mute for fire systems and two NO / NC relays, one that is activated automatically by the auto sleep function and one that can be manually activated by a local latching System Priority button on the WTSD-MIX31K or WTSD-MIX41K.

These relays can be configured to turn the head-end amp rack On or Off with the auto sleep function. The system priority button can be used to take over priority of the room by muting a background music and paging building wide system when the room is in use. The gain headroom limiter settings and indicators help control the balanced audio feed prior to the head-end amp when multiple WTSDs are on a single bus. The limiter can be set to protect a high-power system from over loading the amplifier(s) and possibly damaging the speaker(s).

Features

• Gain Adjust
• Peak Limiter
• Balanced Audio Out with Ground Lift
• TSD Power Supply Input
• Emergency CC Mute
• System Priority Relay
• Auto Sleep Relay
• WTSD RJ45 Bus Input

Specifications

• Input Type –RJ45 Proprietary 8-Wire Bus
• Output Type-Balanced Line Level
• Output Impedance-300 Balanced, 150 Unbalanced
• Level Control-0 to +6dB with 0dB Mark
• Frequency Response-20Hz – 20kHz +/- 1dB
• THD-0.06% @ 1kHz
• Operating Temperature Range-14 – 104 F (-10 – 40 C)
• Height-1.5″ (39mm)
• Width-4″ (101mm)
• Depth-2.75″ (70mm)
• Weight-.375 lbs (0.17kg)

NOTE: 24VDC power supply required and is not included.
