FEATURES

• 30W into 25V/70.7V and 4 Loads
• Rear Mounted DIP Switch Allows Mute Receive for Inputs 2 and 3
• Contact Closure Mute Terminals
• Variable Mute Sensitivity Control for Input 1
• Two Unbalanced, Summing Line Level Inputs
• Balanced Mic/Line/Tel Input w/ Phantom Power
• Automated Diagnostic System Test (Push Here Diagnostic)

SPECIFICATIONS

• FREQUENCY RESPONSE 50Hz – 15kHz
• POWER OUTPUT Max. Average Power @ 50Hz-15kHz with .5% THD, 4 30W RMS
• HEIGHT 3.66″ (93mm)
• WIDTH 8.27″ (210mm)
• DEPTH 10.87″ (276mm)
• WEIGHT 9lb
• SHIPPING WEIGHT 11lb
• VOLTAGE COMPATIBILITY 110V – 120V
