Create a variety of effects with theAmerican DJ Hydro Hybrid, a versatile moving head luminaire that produces a beam, spot, and wash and is well suited for large-scale outdoor and indoor events. The IP65-rated housing provides ample protection to the 420W
Create a variety of effects with theAmerican DJ Hydro Hybrid, a versatile moving head luminaire that produces a beam, spot, and wash and is well suited for large-scale outdoor and indoor events. The IP65-rated housing provides ample protection to the 420W Osram SIRIUS HRI light engine, which creates stunning mid-air effects thanks to an assortment of creative beam-shaping tools and built-in performance macros.
The fixture has two prisms on dual planes, offers motorized zoom and focus, and 2 GOBO Wheels (9 rotating/removable and 14 fixed). Any desired color can be selected from the CMY color mixing system, or choose from the 12 colors on the built-in color wheel. Additionally, there are preset white color temperature macros available to help aid with specific shades of white that can be changed on the fly. The Hydro Hybrid ships with a locking power cord and two Omega brackets.
Features
Specifications
| Fixture Type | Moving Head |
| Light Source | 1x Discharge Bulb – 420 W |
| Colors | Unspecified Colors |
| Beam Angle | 1.6 to 17.7 (Beam) 3.1 to 39.2 (Spot) |
| Control Protocols | DMX512, RDM |
| AC Input Power | 100 to 240 VAC, 50/60 Hz |
| Power / Current Consumption | 580 W (Max) |
| Mounting | Omega Bracket |
Light
| Fixture Type | Moving Head |
| Light Source | 1x Discharge Bulb – 420 W |
| Expected Lamp Life | 4000 Hours |
| Colors | Unspecified Colors |
| Photometrics | 17.7: 52,265fc / 562,600Lux at 16.4′ / 5m 39.2: 21,664fc / 233,200Lux at 16.4′ / 5m |
| Lumen Output | 12,319 Lumens 14,416 Lumens |
| Beam Angle | 1.6 to 17.7 (Beam) 3.1 to 39.2 (Spot) |
| Shutter / Strobe | Electronic |
| Focus | Motorized |
| Zoom Adjustment | Motorized, 1.6 to 39.2 |
| Dimming | Electronic, 0 to 100% |
| Prism | 8-Facet Circular (Rotating) 6-Facet Linear (Rotating) |
Performance
| Operating Modes | Automatic, DMX, Program |
| Macros / Programs | 27x Color Macro Color Mixing Gobo Macro Prism Macro |
| Effects | Frost Filter Strobe (Variable Speed) |
| Gobos | 9x Removable Glass Gobo 14x Fixed Metal Gobo |
| Color Accuracy Index | CRI:77 |
Movement
| Tilt Ranges | 270 |
| Pan Ranges | 630 / 540 |
| Pan/Tilt Inversion | Yes |
Control
| Control Protocols | DMX512, RDM |
| DMX Channel Modes | 3 Mode(s): 24/ 28/ 32-Channel |
| Display / Controls | LCD / 6-Button |
| Remote Control | No |
| Mobile App Compatible | No |
Connectivity
| Inputs/Outputs | 1 x XLR 5-Pin DMX Input 1 x XLR 5-Pin DMX Output |
| Wireless | No |
Power
| AC Input Power | 100 to 240 VAC, 50/60 Hz |
| AC Power Connector | Input:1x Seetronic IP-Rated Output:1x Seetronic IP-Rated Cord Length:5.9′ / 1.8m |
| Fuse | No |
| Power / Current Consumption | 580 W (Max) |
Physical
| Environmental Resistance | Dust/Water-Resistant (IP65) |
| Operating Conditions | -4 to 113F / -20 to 45C |
| Mounting | Omega Bracket |
| Included Accessories | 1x Power Cable |
| Duty Cycle | No |
| Exterior Color | Black |
| Certifications | CE, cETLus |
| Dimensions | 29.17 x 16.31 x 11.4″ / 74.09 x 41.43 x 29cm |
| Weight | 69.7lb / 31.6kg |
