Lighting designers in search of a fixture with creative flexibility for generating vibrant washes, punchy beams, and eye-catching pixel effects should look no further than theAmerican DJ Focus Flex, a compact and versatile moving head luminaire, well suited for event production and rental houses, as well as permanent installations in concert halls, theatres, nightclubs, and churches.
The Focus Flex is powered by seven 40W 4-in-1 (red, green, blue, white) color mixing LEDs, each of which can be controlled independently. It offers a motorized zoom with variable field angle of 6 to 57. With a variety of DMX mode options appropriate for different applications, Focus Flex offers virtual background and foreground color-wheel control and virtual CMY color mixing, as well as a choice of seven DMX modes. The Focus Flex includes a locking power cord, Omega brackets, and a WiFLY antennae.
Features
Specifications
| Fixture Type | Moving Head |
| Light Source | 7x Color LED – 40 W |
| Colors | Red, Green, Blue, White |
| Pixel Configuration | 7x Zone |
| Beam Angle | 4 to 35 |
| Control Protocols | DMX512 |
| AC Input Power | 90 to 240 VAC, 50/60 Hz |
| Power / Current Consumption | 120 VAC, 60 Hz:340 W (Max) |
| Mounting | Omega Bracket |
Light
| Fixture Type | Moving Head |
| Light Source | 7x Color LED – 40 W |
| Expected Lamp Life | 50,000 Hours |
| Colors | Red, Green, Blue, White |
| Pixel Configuration | 7x Zone |
| Photometrics | 4: 3645fc / 39,234Lux at 10′ / 3m 34: 94fc / 1008Lux at 10′ / 3m |
| Color Temperature | 2700 to 10,000K |
| Beam Angle | 4 to 35 |
| Field Angle | 6 to 57 |
| Shutter / Strobe | Mechanical |
| Zoom Adjustment | Motorized |
| Dimming | 16-Bit Electronic, 0 to 100% with 6 Dimmer Modes |
Performance
| Operating Modes | Automatic, DMX |
| Macros / Programs | 20x Auto-Program 64x Color Macro |
| Effects | Strobe (Variable Speed) |
| Gobos | No |
| Refresh Rate | 900 Hz to 25,000 Hz (Adjustable) |
Movement
| Tilt Ranges | 260 |
| Pan Ranges | 630 / 540 |
| Pan/Tilt Inversion | Yes |
Control
| Control Protocols | DMX512 |
| DMX Channel Modes | 7 Mode(s): 16/ 25/ 34/ 42/ 50/ 25/ 28-Channel |
| Display / Controls | LCD / 6-Button |
| Remote Control | WiFly (with Included Equipment) |
Connectivity
| Inputs/Outputs | 1 x USB-A Service Input 1 x XLR 5-Pin DMX Input 1 x XLR 5-Pin DMX Output |
| Wireless Range | WiFly: 2500′ / 762m |
Power
| AC Input Power | 90 to 240 VAC, 50/60 Hz |
| AC Power Connector | Input:1x powerCON Output:1x powerCON |
| Power / Current Consumption | 120 VAC, 60 Hz:340 W (Max) |
Physical
| Environmental Resistance | Dust-Resistant (IP20) |
| Mounting | Omega Bracket |
| Included Accessories | 1x Power Cable |
| Duty Cycle | No |
| Exterior Color | Black |
| Cooling | Fan |
| Certifications | CE, ETL |
| Dimensions | 13.8 x 9.17 x 6.97″ / 35.1 x 23.29 x 17.7cm |
| Weight | 15.5lb / 7kg |
