The ElectraPix Bar 16 Pak features four (4) ElectraPix Bar 16 Battery powered, wireless DMX LED linear fixtures housed in a robust road case with dedicated charging slots for each fixture. It is supplied with an ADJ UC-IR24 remote control that allows simple color selection as well as a power cable which plugs into the side of the case for in-case charging.

Specifications

• 16 Pixel, Hex Color LED (RGBAL+UV) LED Bar
• Battery or Wall Powered
• Up to 20 Hour Battery Operation
• Battery Operation (Menu Option)
• Individual Pixel Control
• Built-In Foreground LED Programs
• Built-In Background LED Programs
• Variable White Color Temperature Control (2,300K ~ 9,900K)
• English & Spanish User Menu
• Built-In Alarm
• Color Calibrated LED’s
• User Selectable LED Refresh Rates (900Hz ~ 25K)
• 6 User Selectable Dim Modes
• 4 User Selectable Dim Curves
• Electronic Strobe (0.3Hz ~ 11Hz)
• Electronic Dimming
• Attach up to two (2) ElectraPix Bar 16 to the Accu Stand VFB1 vertical floor base

Source:

• (16) 20W Hex Color RGBAL+UV Foreground LEDs
• (66) 0.2W RGB Background LED’s
• 50,000 Hour Average Life*
• *May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

Optical:

• 2,300K ~ 9,900K White Color Temperature Range
• 17 Beam Angle
• 45mm Lens Diameter x16

Physical:

• IP65 Housing
• OLED Digital display
• L Track system for locking accessories / rigging
• Glare Shield
• Diffusion Filter slot
• Angle adjustable feet
• Horizontal slide lock to attach additional ElectraPix Bar 16 or ElectraPix Bar 8

Control:

• DMX512
• Aria X2 Wireless Management / DMX System
• Bluetooth
• RDM and RDM Net Compatible
• IR (Includes UCIR24 wireless remote)
• (9) DMX Channel Modes (5, 6, 9,13, 22, 24, 96, 99 & 114 Channel modes)
• On-board Manual Control Mode
• Primary / Secondary Mode

Connections:

• 5pin XLR Outdoor DMX In/Out Sockets (Must be used with STRxxx, 5pin DMX cables to create IP65 seal)
• Outdoor Locking Power Sockets
• Battery Charging Socket

Dimensions & Weight:

• Length: 3.72″ (94.5mm) Width: 45.6″ (1158. 7mm) Height: 10.6″ (268. 7mm)
• Weight: 26.9 lbs. (12.2 kg)

Power:

• AC100-240V/50Hz-60Hz Input
• 90W Power Consumption
• Link 10 pieces @120VAC or 18 pieces @ 230VAC

Battery:

• Rechargeable Lithium ion
• Battery Capacity: 14,000mAh
• Battery Voltage: 22.2V
• Charge Time, AC Power: 5.5 Hours (To Full)
• Charge Time, Flight Case: 5.5 Hours (To Full)
• Up to 20 Hour Battery Operation
• Battery Cycles: 500

Thermal:

• Ambient Operational Temperature: -4F to 113F (-20C to 45C)
• Storage Temperature: -22F to 113F (-30C to 45C)

Certifications & IP Rating:

• CE
• cETLus (Control # 4002034)
• FCC
• IP65

Included Accessories:

• (1) Outdoor Locking Power Cable
• (1) UCIR24 Remote
• (1) 20 Diffusion Filter

Optional Accessories:

• Accu Stand VFB1 (Floor Base)
• LTrack A2 (LTrack Adapter Only)
• LTrack CA2 (LTrack Adapter with Narrow Clamp)
• EPIX B816 IPCB: replacement charging base and power supply

ElectraPix Bar 16 Pak Includes:

• (4) ElectraPix Bar 16 Pak (Fixtures)
• (1) ElectraPix Bar 16 FC (Flight Case)
• (4) ElectraPix Bar 16 IPCB (Charging bases and power supplies)
• (1) UC-IR24 Wireless Infrared Controller
• (1) IP65 Locking Power Cable

ElectraPix Bar 16 Pak Features:

• Houses / Transports and Charges (4) ElectraPix Bar 16 Pak fixtures

ElectraPix Bar 16 Pak Dimensions / Weight (loaded case with 4 fixtures):

• Length: 56.8″ (1443mm)
• Width: 19.6″ (498.4mm)
• Vertical Height: 18.1″ (459.9mm)
• Loaded Weight: 192 lbs. (87 kg)

Flight Case Electrical / Thermal:

• Power Input: AC100VAC~240VAC, 50/60Hz
• IP65 Power Locking Input and Output
• Max Power Consumption: 400Watts
• Power Draw: 4A @ 120VAC or 2A @ 230VAC
• Charge status indicator
• 14F to 113F (-10C to 45C)
