Light up your next indoor / outdoor event with theAmerican DJ ElectraPix Bar 16, an innovative wireless DMX lighting solution that’s packed with advanced features to provide unparalleled control and creativity. The ElectraPix Bar 16 is powered by 16 x 20W RGBAL+UV LEDs and 66 x 0.2W RGB background LEDs with individual pixel control for incredibly dynamic lighting possibilities. Its color-calibrated LEDs, user-selectable dim modes, and electronic strobe/dimming enhance versatility.
Designed for adaptability, the IP65-Rated housing, OLED digital display, L Track system, and adjustable feet make installation and customization a breeze. Additionally, up to two ElectraPix Bar 16 fixtures may be mounted vertically to the VFB1 floor base (sold separately). The fixture’s control options include DMX512, Aria X2 Wireless DMX, Bluetooth, RDM compatibility, and an included UCIR24 wireless remote. The fixture is powered by either batteries or wall outlets and offers up to 20 hours of operation. The ElectraPix Bar 16 ships with an outdoor locking power cable and a 20 diffusion filter.
Features
Specifications
| Fixture Type | Linear/Bar Light |
| Light Source | 16x Color LED – 20 W 66x Color LED – 0.2 W |
| Colors | Amber, Blue, Green, Lime, Red, Ultraviolet |
| Pixel Configuration | 16x Zone |
| Beam Angle | 17 |
| Control Protocols | DMX512, RDM, WiFly |
| AC Input Power | 100 to 240 VAC, 50/60 Hz |
| Battery Type | 22.2 V Lithium-Ion |
| Mounting | Floor Base |
Light
| Fixture Type | Linear/Bar Light |
| Light Source | 16x Color LED – 20 W 66x Color LED – 0.2 W |
| Expected Lamp Life | 50,000 Hours |
| Colors | Amber, Blue, Green, Lime, Red, Ultraviolet |
| Pixel Configuration | 16x Zone |
| Color Temperature | 2300 to 9900K |
| Beam Angle | 17 |
| Shutter / Strobe | Electronic |
| Iris | No |
Performance
| Operating Modes | Color Dimmer, DMX, Primary/Secondary, Program, Static Color |
| Macros / Programs | Color Macro |
| Effects | Strobe Pulse |
| Strobe Rate | 0.3 to 11 Hz |
| Gobos | No |
| Refresh Rate | 900 Hz to 25,000 Hz |
Control
| Control Protocols | DMX512, RDM, WiFly |
| DMX Channel Modes | 9 Mode(s): 5/ 6/ 9/ 13/ 21/ 24/ 96/ 99/ 114-Channel |
| Display / Controls | OLED / 4-Button |
| Remote Control | No |
| Mobile App Compatible | No |
Connectivity
| Inputs/Outputs | 1 x XLR 5-Pin DMX Input 1 x XLR 5-Pin DMX Output |
| Wireless | Wi-Fi *Built-In |
Power
| AC Input Power | 100 to 240 VAC, 50/60 Hz |
| AC Power Connector | Input:1x Seetronic IP-Rated Output:1x Seetronic IP-Rated |
| Power / Current Consumption | 90 W |
| Power Linking | 10 Units at 120VAC 18 Units at 230VAC |
| Battery Type | 22.2 V Lithium-Ion |
| Battery Capacity | 14,000 mAh |
| Approximate Battery Life | All On:Up to 5 Hours Energy Saving:Up to 10 Hours |
| Battery Charging Time | 7 Hours |
Physical
| Environmental Resistance | Dust/Water-Resistant (IP65) |
| Operating Conditions | -4 to 113F / -20 to 45C |
| Mounting | Floor Base |
| Included Accessories | 1x Power Cable 1x Filter |
| Duty Cycle | No |
| Exterior Color | Black |
| Certifications | CE, cETLus, FCC |
| Dimensions | 45.82 x 7.53 x 3.38″ / 116.38 x 19.13 x 8.59cm |
| Weight | Not Specified by Manufacturer |
