TheIP1is part of the Allen & Heath IP Series of remote controllers. It interfaces with theAHM, dLive or Avantis mixing system via standard TCP/IP Network connections and cantherefore be networked with other controllers, computers and third party devices usingstandard Ethernet infrastructure. It is powered over Ethernet (PoE).

The IP1 controls and functions are programmed using the AHM System Managersoftware, dLive Surface / Director software, or Avantis mixer / Director software, and cansuit a number of applications including:

• Zone level control.
• Source selection, for example for background music.
• Scene / Preset selection, for example to recall different room configurations.

Simple to Use

The IP1 is designed with the non-technical user in mind, and can control zone level, source selection or scene/preset recall via a single rotary control.

Visual Feedback

The colour LCD screen gives the user a clear indication of the parameter they are controlling.

Low Maintenance

The IP1 automatically matches firmware with connected devices for easy install and system maintenance.

System Design -Mix and Match

Multiple IP Controllers can be connected to an AHM, dLive or Avantis system to provide control exactly where needed.

Simple to Set Up

Connect –IP1 interfaces with the AHM, Avantis or dLive mixing system via standard TCP/IP Network connections and can be networked with other controllers, computers and third party devices using a standard Ethernet infrastructure.

Configure-The IP1s controls and functions are configured using AHM System Manager, Avantis Director or dLive Director software (PC or Mac), or via an Avantis mixer or dLive Surface.

Specifications

• NetworkFast Ethernet 100Mbps
• PoE802.3af
• Max power consumption2.5W
• Operating Temperature Range0 deg C to 35 deg C (32 deg F to 95 deg F)
• Dimensions (WxDxH) –1.77 x 0.98 x 4.17 (45 x 25 x 106 mm)
• Weight –0.22 lb (99.2g)

What’s in the Box

• IP1 Remote Controller
• Fitting notes AP11269 (US) / AP11270 (EU)
• Safety Sheet
