TheAllen & Heath CC-10 Touch Panelis designed as the perfect control companion for your installed AHM matrix processors, dLive, or Avantis systems. Powered by the Allen & Heath Custom Control App, the CC-10 connects to your system via Ethernet and can be p
TheAllen & Heath CC-10 Touch Panelis designed as the perfect control companion for your installed AHM matrix processors, dLive, or Avantis systems. Powered by the Allen & Heath Custom Control App, the CC-10 connects to your system via Ethernet and can be powered over Ethernet or via an included DC adapter. It utilizes a 75x75mm VESA mount pattern and can be wall or desktop mounted. Allen & Heath offers the dedicated CC-STN desktop stand, or CC-BRK wall mount bracket (sold separately).
Features
Specifications
| Display Size | 10″ |
| Native Resolution | 1280 x 800 |
| Maximum Brightness | 500 nits / cd/m2 |
| Touchscreen Technology | Projected Capacitive |
| Wireless | No |
| USB I/O | 1x USB-A 2.0 (Service/Control) |
| Ethernet I/O | 1x RJ45 Gigabit Ethernet |
| Built-In Speakers | No |
| Media Card Reader | No |
Display
| Display Size | 10″ |
| Aspect Ratio | 16:10 |
| Display Orientation | Landscape |
| Native Resolution | 1280 x 800 |
| Maximum Brightness | 500 nits / cd/m2 |
| HDR Support | No |
| Contrast Ratio | 800:1 |
| Viewing Angle (H x V) | 160 x 160 |
| Pixels Per Inch (ppi) | 151 ppi |
Surface
| Touchscreen Technology | Projected Capacitive |
| Multi-Touch Points | 5 |
Video
| TV Tuner | No |
Connectivity
| Wireless | No |
| USB I/O | 1x USB-A 2.0 (Service/Control) |
| Ethernet I/O | 1x RJ45 Gigabit Ethernet |
| Multi-Input Support (PIP/PBP) | No |
Speaker
| Built-In Speakers | No |
Hardware
| OS Compatibility | Android/iOS |
| Mobile App Compatible | Yes: Android & iOS App Name: Allen & Heath Custom Control |
| Media Card Reader | No |
Electrical
| Input Power | 12 VDC at 2 A |
| Power Adapter Type | External |
General
| Operating Conditions | 32 to 104F / 0 to 40C |
| Mounting-Hole Pattern | 75 x 75 mm |
| Bezel Thickness | 22.3 mm (Bottom/Top) 18.9 mm (Right/Left) |
| Dimensions | 10.1 x 7.1 x 1.1″ / 255.3 x 181 x 26.7mm |
Packaging Info
| Package Weight | 2.37 lb |
| Box Dimensions (LxWxH) | 14.9 x 9.9 x 2″ |
