ADAM Audio has developed the unique Sub2100 subwoofer for the special requirements of large control rooms and studios. The Sub2100 combines a huge 21.5 woofer and an amplifier capable of 1000W continuous power housed in a bass reflex enclosure tuned for reproducing frequencies down to 18Hz. The sheer power and extremely high efficiency (99dB/ W/m) enable this system to produce linear SPL peaks of 128dB without any significant compression.

The worlds largest voice coil

Essential to the volume of this woofer is the gigantic 6 voice coil. Equipped with this voice coil, the Sub2100 is capable of reaching the highest SPLs in the lowest frequencies that can be perceived by the human ear. On every level, the Sub2100 establishes a new benchmark in subwoofer technology.

Features

• Linear bass reproduction down to 18Hz
• Maximum Peak sound pressure in 1 m 128dB
• High-efficiency 1000W PWM amplifier
• Special 21.5″ woofer with 6″ voice coil
• Easy manual or automatic (de-)activation
• Upper cutoff frequency is selectable between 50Hz and 150Hz
• Switchable highpass filter for satellite outputs, rolls off signal below 85Hz
• Subwoofer 180 Phase (polarity) reverse switch
• Analog XLR and RCA inputs and satellite outputs
• XLR Sub Out for cascading additional subwoofers
• 2-year warranty; optional extension to 3 years upon product registration

Specifications

• Powered: Yes
• Speaker Size: 21.5″ Subwoofer
• Driver Type: Paper Cone
• Total Power:1000W RMS
• Frequency Range: 18Hz-150Hz
• Crossover Frequency: 50Hz-150Hz
• Maximum Peak SPL: 128dB SPL @ 1m
• Input Types: 2 x XLR, 1 x Dual RCA Stereo
• Output Types: 2 x XLR (satellite out), 1 x XLR (sub out), 1 x Dual RCA Stereo (satellite)
• Height: 33.5″
• Width: 23.5″
• Depth: 28″
• Weight: 187.4 lbs.
